Vantec 600W ION2+80+ - ATX12V v2.3, 135mm Fan, SLI Ready
6x SATA, 1x PCI-E 8-pin, 1x PCI-E 6-pin

No Longer Available

Part Number:

104621

(?) Brand:

Vantec Web Site

Manuf No:

VAN-600AS
VAN600AS

Shipping Weight:

3 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

VAN600AS, VAN-600AS, PSVAN600AS

Vantec's ION2 + 600W Power Supply is ideal for case modders and regular users alike. It provides steady efficiency under different peak level and protection against consumption of energy and money. ION 2+ A series, it's equipped greater than 80% efficiency, and with compliance with ATX 12V V2.3/Intel & EPS 12V V2.92/SSI. In view of meeting graphics card development, ION 2+ 550W comes with connectors of 8 pin PCI-E and 6 pin PCI-E to help consumers solve the problem of power consumption in the future. It has 135 mm temp. controlled fan that provides itself a solid working environment and lowers noise emissions. The idea design allows consumers to enjoy decent efficiency & performance of computing experience, also provides a stable & comfortable environment meanwhile.

Features:

Built-in active-PFC, power utilization rat up to 99% or higher.

80Plus compliant with more than 85% efficiency

Compliance with Intel ATX 12V V2.3

Compliance with the newest SSI EPS 12V V2.92

Intelligent 135mm temperature control fan design, augmenting cooling effect and reducing the noise.

Output of 2 individual sets +12V,out put is stable, 100% compliant with the Intel Specification

Cable-management design to eliminate clutter and improve airflow inside the chassis

SLi supported and nVIDIA(SLi) certificated

Upgradeable: Built-in6 sets of SATA connectors

Higher reliability (MTBF > 50,000 hours)

Specifications:

Model:	VAN-600AS
AC Input:	115V~230V / 10A~6A /50~60Hz
DC Output:	+3.3V +5V +12V1 +12V2 -12+5Vsb
Max Output Current:	24A24A 22A22A0.5A 2.5A
Max Combined:	150W 432W18.50W
Wattage:	600W

Package Contents:

ION2+ PSU

User's manual

Screw

Power cord

No additional files, specification sheets, guides or documentation found for product.

Warranty: 5-year Manufact.
