ASUS M4A78-EM-1394 Motherboard
  • AM2+, AMD 780G, SB710, HT 5200, 4xDDR2-1200, 1xPCI-Ex16v2.0, 5xSATA, 1xeSATA, RAID, 1xGigLAN, 8Chl-HD, Firewire, VGA/DVI, mATX

IMG 1 of 4
No Longer Available
Part Number:
120615
(?) Brand:
ASUS Web Site
Manuf No:
M4A78-EM/1394
M4A78EM/1394
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
M4A78EM/1394, M4A78-EM/1394, MBDASUM4A10F
Features


CPU, Chipset and Graphics Features

AMD Phenom II/Athlon II/Sempron 100 Series Processors(AM3 CPU)

This motherboard supports AMD AM3 multi-core processors with unique L3 cache and delivers better overclocking capabilities with less power consumption. It features dual-channel DDR2 1066 memory support and accelerates data transfer rate up to 5200MT/s via HyperTransport 3.0 based system bus. This motherboard also supports AMD CPUs in the new 45nm manufacturing process.
AMD 780G + SB710

AMD 780G Chipset is designed to support up to 5200MT/s HyperTransport 3.0 (HT3.0) interface speed and PCI Express 2.0 x 16 graphics. It is optimized with AMDs latest AM3/AM2+ and multi-core CPUs to provide excellent system performance and overclocking capabilities.
HDMI Support

Enjoy Full HD 1080p Multimedia Home-Theater Entertainment
High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals through through a single cable. Supporting HDCP copy protection such as HD DVD and Blu-ray Discs, HDMI provides you with the highest-quality home theater experience.



AMD Phenom X4/ Phenom X3/ Athlon X2/ Athlon/ Sempron processors (socket AM2+/AM2)

This motherboard supports AMD Socket AM2+ multi-core processors. It features dual-channel DDR2 1066 memory support, data transfer rate up to 5200MT/s via HyperTransport 3.0 based system bus, and AMD Cool n QuietTM Technology.
O.C. DDR2 1200

To attain top performance, ASUS engineers have successfully unleashed DDR2 1200(O.C.) MHz to meet the higher bandwidth requirements of the latest operation system, 3D graphics, multimedia, and Internet applications.

*Ensure that you download and update to the latest BIOS at www.asus.com and purchase the memory modules listed in the ASUS official memory Qualified Vendors Lists (QVL).
** We recommend that you install the DDR2 1200 memory modules on the yellow slots for better performance.

PCIe 2.0 support

This motherboard supports the latest PCIe 2.0 devices for double speed and bandwidth which enhances system performance.
Hybrid CrossFireX Support

Boosted Performance with onboard GPU and discrete graphics card
ATI Hybrid CrossFireX technology is a unique hybrid multi-GPU technology. It takes your gaming experience to the next level boosting PC performance by enabling the chipsets integrated graphics processor and a discrete GPU to operate simultaneously with combined output for blisteringly-fast frame rates unleashing the graphics performance (Windows Vista OS only).

ASUS Green Design

EPU

The ASUS EPU (Energy Processing Unit) provides total system power management by detecting current PC loadings and intelligently moderating power in real-time. It automatically provides the most appropriate power usage for the CPU, VGA card, hard drives, and CPU/chassis fans- helping save power and money!



ASUS Overclocking Tools

Turbo Key

ASUS Turbo Key allows the user to turn the PC power button into an overclocking button. After the easy setup, Turbo Key can boost performances without interrupting ongoing work or games - with just one touch!!

Express Gate

Express Gate

5 Secs Bootup to online
Express Gate is the one-stop gateway to instant fun! Its a unique motherboard built-in OS. You can utilize the most popular Instant Messengers (IM) like MSN, Skype, Google talk, QQ, and Yahoo! Messenger to keep in touch with friends, or quickly check on the weather and e-mails just before leaving your house. Whats more, the user-friendly picture manager lets you view your pictures without entering Windows at anytime! * The actual boot time is subject to hardware configurations and product models

ASUS EZ DIY

EZ Flash 2

EZ Flash 2 is a user-friendly BIOS update utility. Simply launch this tool and update BIOS from a USB flash disk before entering the OS. You can update your BIOS only in a few clicks without preparing an additional floppy diskette or using an OS-based flash utility.
CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a USB flash disk containing the BIOS file. This utility saves users the cost and hassle of buying a replacement BIOS chip.

Other ASUS Features

MyLogo2

Personalize your system with customizable boot logo
You can convert your favorite photo into a 256-color boot logo for a more colorful and vivid image on your screen.
ASUS Q-Fan

ASUS Q-Fan technology intelligently adjusts CPU fan speeds according to system loading to ensure quiet, cool and efficient operation.

Industry Standard

High Definition Audio

Enjoy high-end sound system on your PC!
The onboard 8-channel HD audio (High Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio output, jack-sensing feature, retasking functions and multi-streaming technology that simultaneously sends different audio streams to different destinations. You can now talk to your partners on the headphone while playing a multi-channel network games. All of these are done on one computer.

RoHS

GreenASUS

The motherboard and its packaging comply with the European Unions Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers health while minimizing the impact on the environment.
S/PDIF-out on Back I/O Port

This motherboard provides convenient connectivity to external home theater audio systems via coaxial and optical S/PDIF-out (SONY-PHILIPS Digital Interface) jacks. It allows to transfer digital audio without converting to analog format and keeps the best signal quality.

IEEE 1394a interface

IEEE 1394a interface provides high speed digital interface for audio/video appliances such as digital television, digital video camcorders, storage peripherals & other PC portable devices.

Specifications

CPU AMD AM3/AM2+/AM2 ;PhenomII /AthlonII /Phenom / Athlon /Sempron Processors
AMD Cool 'n' Quiet Technology
Support 45nm CPU
Support CPU up to 125W
*Refer to www.asus.com for the AMD CPU support list
Chipset AMD 780G/SB710
System Bus Up to 5200 MT/s HyperTransport 3.0 interface for AM3 / AM2+ CPU
2000 / 1600 MT/s for AM2 CPU
Memory 4 x DIMM, Max. 16 GB, DDR2 1200(O.C.)/1066*/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1200/1066 is supported by AM2+/AM3 CPU for one DIMM per channel only.
*We recommend that you install the DDR2 1200 memory modules on the yellow slots for better performance.
*Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
*Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
Expansion Slots 1 x PCIe x16
1 x PCIe x1
2 x PCI
VGA Integrated ATI Radeon HD3200
Max. shared memory: 256 MB
Supports DVI-D with HDCP compliant with max. resolution 2560x1600 (@ 60Hz dual-link)
Supports HDMI Technology with max. resolution up to 1920 x 1200 (1080P)
Supports RGB with max. resolution 2048 x 1536 (@85Hz)
Hybrid CrossFireX Support (For Windows Vista only)
Dual VGA output support:
RGB & DVI
RGB & HDMI
*Refer to www.amd.com for the Hybrid CrossFireX selected GPUs.
*To playback the HD-DVD and Blu ray Disc we recommended system configuration above Graphic shared memory 256MB/Dual-Core CPU minimum/Minimum 1GB memory of Dual-channel DDR2 667 or Single -chanel DDR2 800.
Storage Chipset
1 xUltraDMA 133/100
5 xSATA 3 Gb/s ports Support RAID 0,1,10
1 x External SATA 3Gb/s support JBOD

*Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only. For more information, please refer to https://support.microsoft.com/kb/946557/en-us
LAN PCIe Gb LAN
Audio ALC887 High Definition Audio 8 -Channel CODEC
Supports Jack-detect and Multistreaming teconologies
Supports S/PDIF out interface
USB 12 USB 2.0 ports (6 ports at mid-board, 6 ports at back panel)
Overclocking Features SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz to 550MHz at 1MHz increment
Adjustable DRAM Voltage
ASUS C.P.R.(CPU Parameter Recall)
Special Features - ASUS EPU-4 Engine
- ASUS Express Gate
- ASUS Turbo Key
- ASUS Q-Fan
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- ASUS AI NET 2
- All solid capacitor
Back Panel I/O Ports 1 x DVI
1 x VGA
1 x HDMI
1 x External SATA
1 x IEEE 1394a
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O
1 x PS/2 Mouse / Keyboard port 1 x Optical S/PDIF_OUT port
Internal I/O Connectors 3 x USB connectors supports additional 6 USB 2.0 ports
1 x IDE connector
5 x SATA connectors
1 x IEEE 1394a connector
1 x LPT connector
1 x S/PDIF Out connector
1 x CPU / 1 x Power / 1 x Chassis Fan connectors
1 x CD audio-in connector
1 x High Definition Front panel audio connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V Power connector
1 x COM connector
1 x System Panel connector
BIOS 8 Mb Flash ROM
AMI BIOS, PnP, DMI v2.0, WfM2.0, ACPI v2.0a, SMBIOS 2.5
Accessories User's manual
1 x I/O Shield
1 x UltraDMA 133/100/66 cable
1 x SATA cable
Support Disc Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS LiveUpdate Utility
Form Factor uATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
