No Longer Available

Part Number:
121168
(?) Brand:
Manuf No:
G41T-M
G41TM
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
All stock codes associated to this product
G41TM, G41T-M
Features


LGA775
Supports LGA775 Intel processors with HT Technology.
Certified For Windows 7
Windows 7 platform introduces a number of manageability improvements that can reduce total cost of ownership by helping to increase automation, improve user productivity, and provide flexible administrative control to meet compliance requirements. It is more user-friendly and has been optimized to consume less system resources with Windows 7 as well. Furthermore, the VT technology is enhanced to support real-time multimedia application including video playback and 3D games.
10/100 LAN
Provides 10/100 Mbps solution to your network or broadhand connection without having to buy an extra LAN card.
Dual Channel DDR2 800
Doubles the bandwidth of your system memory up to 12.8GB/s and pumps up the system performance.
FSB1333
Supports the latest 1333MHz front side bus Intel Processor
6 Channel High Definition Audio
Integrated 6-channel HD Audio CODEC delivering advanced multi-channel audio and bringing you the experience of home theater-quality sound.
SATAII 3.0Gb/s
Doubles the transfer speed of SATA, running at speed up to 3.0Gb/s, and fully compatible with the soon-to-be-released SATA HDD, CD-ROM and other cutting-edge devices with NCQ function support.
Certified For Windows Vista
The latest generation Microsoft O.S., delivers better personal productivity and digital entertainment on your PC through its improved reliability, security, and performance.
Core 2 Duo
The processor is manufactured on Intel's 65nm fab process, regardless of L2 cache size, resides in an LGA775-style socket and runs up to 1333MHz front-side bus. Its power consumption is really much lower than previous Intel desktop chips.
USB 2.0
The latest connectivity standard which delivers transfer speeds up to 480Mb/s for easy connectivity and ultra-fast data transfers.

Specifications


  CPU
LGA775 socket for latest Intel  Core 2 Quad /Core 2 Duo / Pentium Dual-core /Celeron processors
FSB 1333/1066 MHz

  CHIPSET
Intel  G41 & ICH7
North Bridge: Intel  G41
South Bridge: Intel  ICH7

  GRAPHICS
Integrated Intel  Graphics Media Accelerator X4500 (GMA X4500)

  MEMORY
Dual-channel DDR2 memory architecture
2 x 240-pin DDR2 DIMM socket support up to 8 GB
Support DDR2 667/800 MHz Memory

  EXPANSION SLOT
1 x PCI Express x16 slot
2 x PCI Express x1 slots
1 x PCI slot

  STORAGE
Supported by Intel ICH7
2 x Ultra DMA100/66 devices
4 x Serial ATAII devices

  AUDIO
VIA  VT1708B 6-channel HD Audio

  LAN
Atheros AR8112 10/100 LAN

  REAR PANEL I/O
1 x PS/2 keyboard & PS/2 mouse connectors
4 x USB ports
1 x VGA port
1 x COM Port
1 x RJ45 LAN connector
1 x Audio port (3 holes jack)

  INTERNAL I/O CONNECTORS & HEADERS
1 x 24-pin ATX Power Supply Connector & 4-pin 12V Connector
4 x Serial ATA connectors
2 x USB 2.0 headers support additional 4 USB Ports
1 x LPT header
1 x Clear CMOS header
1 x Front panel audio header
1 x Front panel header
1 x S/PDIF out header, 1 x CD-in header
1 x SPK header
CPUFAN/SYSFAN headers

  SYSTEM BIOS
AMI BIOS with 8Mb SPI ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Supports ACPI revision 1.0 specification

  FORM FACTOR
Micro-ATX Size, 244mm*204mm

* The information above is provided as reference only and is subject to change without notice.
* All trademarks are property of their respective holders.


No additional files, specification sheets, guides or documentation found for product.

Warranty: 2-year Manufact.

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
