Auzentech X-Studio 5.1 Soundcard

IMG 1 of 1
No Longer Available
Part Number:
121255
(?) Brand:
Auzentech
Manuf No:
AZT-STUDIO
AZTSTUDIO
Shipping Weight:
3 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
AZTSTUDIO, AZT-STUDIO

The Auzen X-Studio is a low profile sound card with 5.1 channel surround sound. It has DirectSound 3D, A3D, EAX 1.0/2.0 and has a standard PCI 2.1, 2.2 interface. This sound card has swappable OPAMP for Front channel and internal digital output via 2-pin connector and QSOUND 3D Surround Engine Driver support (DirectSound 3D, A3D, EAX 1.0/2.0). It has a Filtering Circuit / +6dB Gain of Pre-amp for MIC and Optical 24-bit/ 96kHz digital output support, it also has HD Front Panel Audio Support.

Technical Specifications
Interface Core

  • VIA ICE 1723 Audio Processor

  • PC Interface PCI 2.1, 2.2 Compliant Interface

  • Two-Pin Digital Output Port

  • MIC Pre-Amp Gain +6dB

  • TI NE5532P High-Performance Operational Amplifier (OPAMP)

  • Swappable OPAMP Socket

  • Optical Digital Out (24-bit/96kHz Output)

  • LP(LowProfile) type supports

  • FP(Front Panel)_ Audio

  • QSOUND 3D



I/O Connectors
Onboard connections

  • MIC Input

  • Line Input

  • G9 Port

  • SPDIF(Optical) digital Output: 48 kHz / 96kHz

External Connector(G9 Multi output Cable)

  • SPDIF(Coaxial) Digital output

  • 3 Line Outs(Front, Side, Center/Sub.W), Stereo (3.5mm)18Bit/48kHz

  • 1 Headphone Out, stereo (3.5mm) 18 Bit / 48 kHz

  • Line In, stereo (3.5 mm) 18 Bit / 48 kHz

  • Microphone In, mono (3.5 mm) 18 Bit / 48 kHz

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.
