WNAP210(ACCESSPT) | Netgear WNAP210 ProSafe Wireless N Access Point - 802.11b/g/n

Advanced Speed and Range with Comprehensive Internet Security

• Up to 10x the coverage and 15x the speed of 802.11g networks
• Backward compatible to 802.11g devices while simultaneously providing faster wireless networking for 802.11n devices
• Security features include WPA, WPA2, rogue AP detection and 802.1x with RADIUS support
• Can run on 802.3af PoE for easy placement in optimal locations- desktop, wall-mount or ceiling
• Internal antennas for optimized antenna configuration without user guesswork
• Comprehensive SNMP functionality for advanced network management
• Deploy over large areas with point-to-point and point-to-multipoint bridging over large areas with Wireless Distribution System (WDS)
• Mounting kit provides for wall or ceiling placements

Standards

• IEEE 802.11n draft 2.0 specification, 2.4 GHz
• IEEE 802.11g, IEEE 802.11b, 2.4 GHz
• IEEE 802.3af Power over Ethernet (PoE)

Physical Specifications

• Dimensions: 223.5 x 153.2 x 28 mm (8.79 x 6.03 x 1.10 in)
• Weight: .41 kg (.90 lb)

Physical Interfaces

• One (1) 10/100/1000BASE-T Gigabit Ethernet (RJ-45) port with Auto Uplink (Auto MDI-X) with IEEE 802.3af Power over Ethernet (PoE) support
• Power adapter: 12V DC, 1A; plug is localized to country of sale
• Four (4) LEDs: Power, test, LAN, WLAN

Power

• Power over Ethernet (PoE consumption: 5.8W)

Security

• Wi-Fi Protected Access (WPA, WPA2)
• Wired Equivalent Privacy (WEP) 64-bit, 128-bit, and 152-bit encryption for IEEE 802.11b and IEEE 802.11g
• I EEE802.1x RADIUS authentication with EAP TLS, TTLS, PEAP
• Wireless access control to identify authorized wireless network devices
• MAC address authentication VPN pass-through support
• Secure SSH telnet
• Secure Sockets Layer (SSL) remote management login
• Ability to configure 8 BSSIDs and 9 VLANs to provide more granular access to the network based upon user type
• Rogue AP detection

Network Management

• Remote configuration and management through Web browser, SNMP or telnet with command line interface (CLI)
• SNMP management supports SNMP MIB I, MIB II, 802.11 MIB and proprietary configuration MIB

Advanced Wireless Features

• Wireless Distribution System (WDS)
  • Point-to-point wireless bridge mode
  • Point-to-multipoint wireless bridge mode
  • Repeater mode
  • Wireless Client mode
• Adjustable transmit power control (TPC) from 100 mW down to 0 mW
• WMM - Wireless MultiMedia prioritization

  Package Contents

  • ProSafe Wireless-N Access Point (WNAP210)
  • Ethernet cable
  • Wall-mount kit
  • Installation guide
  • Resource CD
  • 12V, 1A power supply
  • Warranty/support information card

  System Requirements
