Repotec RP-SW16P Switch - 16-port 10/100Mbps Nway, Rackmountable

IMG 1 of 1
No Longer Available
Part Number:
125585
(?) Brand:
Repotec
Manuf No:
RP-SW16P
RPSW16P
Shipping Weight:
4 KG (Includes product packaging)
Estimate Shipping
Date Added:
10/9/2009
Details Files Images & Video
All stock codes associated to this product
RPSW16P, RP-SW16P

RP-SW16P
The Switch are designed to allow simultaneous transmission of multiple packets via an internal high-speed data channel. This means that it can partition a network more efficiently than bridges or routers in most environments. This 16/24 port Ethernet Switch is a highly reliable network Switch and is the ideal device for bridging Ethernet to Fast Ethernet workgroups or networks. Simple and cost-effective, the 16/24 port Switch Ethernet supports IEEE 802.3 10Base-T Ethernet and IEEE 802.3u 100Base-TX Fast Ethernet. The 16/24 port Switch is therefore fast being recognized as one of the most important building blocks for today networking technology.


FEATURES
  Complies with 10Base-T specifications of the IEEE 802.3 standard
  Complies with 100Base-TX specifications of the IEEE 802.3u standard
  RJ45 ports for 100Base-TX and 10Base-T connectivity
  Supports Nway protocol for speed (10/100Mbps) and Duplex mode (Half/Full) auto-detection
  Supports Auto MDI/MDI-X crossover
  Supports Full and Half Duplex operation on all ports
  Supports back-pressure (Half Duplex) and Flow Control (IEEE 802.3x)
  Wire-speed packet filtering and forwarding rate
  Store-and-forward architecture filters fragment & CRC error packets




SPECIFICATIONS

Standards  IEEE 802.3, IEEE 802.3u and IEEE 802.3x
Media Support  10Base-T: Cat.3, 4 or 5 TP
 100Base-TX: Cat.5 TP
Bandwidth  200/100/20/10Mbps
Forwarding / Filtering Rate  10Mbps: 14,880pps/14,880pps
 100Mbps: 148,800pps/148,800pps
MAC Addresses  Supports up to 8K MAC address
Buffer Memory  Embedded 160Kbytes packet buffer
Duplex Modes  Auto-Negotiation
Crossover  Auto MDI/MDIX Crossover function for each port
LED Indicators  System: Power
 Port: Link/Activity, 10/100Mbps
Power Supply  Internal power supply 100~240VAC
Environment  Operating Temperature: 0C ~ 45C
 Operating Humidity: 10% ~ 90% (Non-Condensing)
Dimension  432 * 220 * 44 mm
Certifications  FCC, CE




APPLICATIONS





ORDERING INFORMATION

RP-SW16P 16-P Nway Ethernet Switch

No additional files, specification sheets, guides or documentation found for product.

Warranty: 2-year RTB

Full manufacturers warranty details are available at the manufacturers web site.
