Addonics Multilane Bridge for SATA Storage - SCSI-I to 4xSATA

IMG 1 of 2
No Longer Available
Part Number:
127477
(?) Brand:
Addonics Web Site
Manuf No:
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
, AD4SAML

Implementing the reliable Infiniband cabling in external SATA storage system is easy and simple using the Addonics family of Multilane SATA converters. The Multilane bridge for the SATA controller easily adds a multilane connector to any desktop system, server or equipment via a PCI mounting bracket. With this bridge, up to 4 internal SATA/SATA II ports can be set up for external SATA connection.

The Multilane bridge for the SATA storage is designed to mount easily into Addonics Storage Tower or any multi-bay SCSI drive enclosures via the standard SCSI I connector opening. This bridge also supports connecting up to 4 SATA storage devices to a single Multilane connector.

Product features

Multilane bridge for SATA storage (ADSAML)

  • Connects up to 4 SATA hard drive to one Multilane connector
  • Mounts inside Addonics Storage Tower with PM back panel
  • Fits multi-bay SCSI drive enclosures via the standard SCSI-I (centronic 50-pin) opening

Specifications:

  • Support SATA I and SATA II
  • 4X Multilane connector with thumb screw support
  • Fully compliant with SFF 8470 Specification
  • Cross-Over Pinouts
  • Dimension:
    Model
    PCB
    mounting bracket
    AD4SAML 43 x 45 mm
    (1.71 x 1.76 in)     		84 x 47 x 23 mm
    (3.32 x 1.84 x .9 in)
  • 1 year warranty

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Addonics) web site.
