JFS524E-100AJS | Netgear JFS524E Ethernet Switch - 24-Port 10/100

More Capabilities beyond Plug-and-play Connectivity

Today's growing businesses are both placing more demands on and relying more on their network. Companies are putting more applications and demands on their Ethernet Infrastructure. Using VoIP phones and IP cameras require more than simple plug-and-play connectivity. Additionally, Internetbased applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. NETGEAR's new ProSafe Plus Switches meet this growing need by providing easy to use visibility and limited configuration capabilities. To provide more insight into the network behavior, ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally, if there are connectivity issues, these switches offer a cable diagnostic test capability that can identify and even locate problems in the cables. To optimize traffic through the switches, ProSafe Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. Also, as a means of improving security or managing collision domains, ProSafe Smart Switches offer VLAN technology. ProSafe Plus Switches offering these monitoring and configuration capabilities at a slight cost premium over un anaged switches, delivering great value to the end user.

Additionally, furthering NETGEAR's support of the environment, ProSafe Plus Switches have powersaving Green Ethernet technology. The JFS524E is the first 24-port Fast Ethernet on the market with such Green Ethernet features. The switch comes in a sturdy metal case with a fan-less design for silent operation.

Features

• Use as a plug-and-play switch or use the Configuration Utility for simple setup
• 24 ports deliver up to 200 Mbps bi-directional bandwidth on each port
• Quality of Service (QoS) for prioritizing network traffic
• Virtual LAN (VLAN) support for network segmentation and security
• Troubleshoot connection problems via cable test
• Bandwidth management to avoid network congestions
• Network traffic monitoring
• Port Mirroring
• Broadcast Storm Control

NETGEAR Green

• Up to 63% lower power consumption¹
• Auto power-down mode conserves energy when a port is not connected
• Less transmit power when the cable is short (under 10 m)
• Packaging manufactured with at least 80% recycled material

¹Maximum power savings when compared to the equivalent NETGEAR Unmanaged product.

• IEEE 802.3i 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3x full-duplex flow control
• Honors IEEE 802.1p priority tags
• Honors IEEE 802.1Q VLAN tags
• Compatible with all major network software

• Twenty-four (24) 10/100 Mbps Ethernet RJ-45 ports

• 100-240V, 50-60Hz, 1.2A max, localized to country of sale
• Power consumption: 5.9W

• Unit: Power
• Per network port: 10 or 100 Mbps operations, Rx/Tx and collision, link, half/full duplex

• MAC address: 4 K
• Bandwidth: 4.8 Gpbs

• Dimensions: (h x w x d) 43 x 330 x 173 mm (1.7 x 13 x 6.8 in)
• Weight: 1.43 kg (3.15 lb)

• Operating temperature: 32 to 122 F (0 to 50 C)
• Operating humidity: 90% maximum relative humidity, non-condensing
• Acoustic noise level: 0
• Mean time between failures (MTBF): 1,952,478 hours (~ 223 years)

• CE mark (commercial), FCC Part 15 Class A, EN 55022 (CISPR 22) Class A, VCCI Class A, C-Tick, KCC

• UL listed (UL 1950)/CUL, CB, CCC

• PMB0331-100 (US)
• PMB0331 (non-US)

• PRR0331

• ProSafe Plus 24-port Fast Ethernet Switch (JFS524E)
• Rack-mount kit
• Power cord
• Quick Install Guide
• Installation CD with Configuration Utility software
