Netgear WG103 ProSafe Wireless Access Point - 802.11g, POE Support, Up to 108Mbps

IMG 1 of 1
No Longer Available
Part Number:
131855
(?) Brand:
Netgear Web Site
Manuf No:
WG103
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
WG103, 606449062052
ProSafe 802.11g Wireless Access Point WG103

Intelligent Networking Features for a Scalable, Secure Solution

High-speed IEEE 802.11g, up to 108 Mbps in turbo mode

Comprehensive SNMP functionality for advanced network management



Intelligent Networking Features for a Scalable, Secure Solution

  • High-speed IEEE 802.11g, up to 108 Mbps in turbo mode
  • Extensive Security features include WPA2, multiple BSSID, rogue AP detection, MAC address filtering and 802.1x with RADIUS support
  • Flexible AP placement with integrated 802.3af Power over Ethernet
  • Accepts high gain accessory antennas for greater coverage


Features

  • High-speed IEEE 802.11g, up to 108 Mbps in turbo mode
  • Extensive Security features include:
    • WiFi Protected Access (WPA/WPA2), 802.11i
    • Multiple BSSID
    • Rogue AP detection
    • MAC address filtering
    • 802.1x with RADIUS support
    • WPA2 data encryption when using WDS bridging
    • Disable/enable SSID broadcast
  • Comprehensive SNMP functionality for advanced network management
  • Quality of Service (QoS) with wireless multi-mode (WMM)
  • Save battery power for clients with wireless multi-mode power save (WMM-PS)
  • Deploy over large areas with Wireless Distribution System (WDS):
    • Point-to-point bridging
    • Point-to-multipoint bridging
    • Repeating
    • Client mode (future release)
  • Accepts high-gain accessory antennas for greater coverage
  • Sturdy metal chassis with Kensington Lock slot
  • Plenum-rated for safe and convenient placement above drop-down ceilings
  • Support for IEEE802.3af Power over Ethernet (PoE):
    • Allows flexible AP placement not limited to outlet location
    • Use full 100 meter distance of Ethernet cable
    • Eliminates extra power cables

/images/extra/13/1/e2009120365360.jpg /images/extra/13/1/e2009120398140.jpg

Physical Specifications
  • Dimensions: 158 x 101 x 29mm
    (6.22 x 3.97 x 1.14 in)
  • Weight: 402.5 g (0.88 lb)
Processor and Memory
  • Atheros, 8 MB flash, 32 MB SDRAM
Wireless
  • I EEE 802.11g 54 Mbps Wireless Access Point
  • Antenna: 5 dBi, 2.4 GHz detachable
  • Typical maximum transmit output power (varies based on country and/or region selection to ensure local regulatory compliance): 20 dBm
Advanced Wireless Features
  • WDS point-to-point wireless bridge mode
  • WDS point-to-multipoint wireless bridge mode
  • WDS repeater mode
  • Adjustable wireless output power
Network Management
  • Remote configuration and management through Web browser, or SNMP (v1, v2c)
Physical Interfaces
  • One (1) 10/100BASE-T Ethernet (RJ-45) port with Auto Uplink (Auto MDI-X) with IEEE 802.3af Power over Ethernet (PoE) support
  • One (1) reverse SMA antenna connector
Lighted Status LEDs
  • Power, test, LAN, and WLAN 802.11g
Security
  • 40-bit (also called 64-bit), 128-bit, Wired Equivalent Privacy (WEP) Encryption, WiFi Protected Access Pre-shared Key (WPA-PSK, WPA2-PSK)
  • Rogue AP detection
  • IEEE 802.1x authentication
  • MAC address filtering
  • 8 BSSID
  • Kensington Lock slot for physical security
  • Secure SSL browser connection
  • Number of VLANs: 9
Power
  • Power adapter: 12V DC, 1.0 A; plug is localized to country of sale
  • PoE power consumption: 5W
Package Contents
  • ProSafe 802.11g Wireless Access Point (WG103)
  • One (1) 5 dBi detachable antenna
  • Resource CD
  • Power adapter
  • Ethernet cable
  • Installation guide

Specification Sheets / Installation guides / Associated files

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Netgear) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
