Accelerate your desktop network with Gigabit connectivity for up to 5 devices. Ultra-fast speed, automated performance optimization, and advanced error correction. The Gigabit 5-Port Workgroup Switch is designed to deliver premium performance ideal for anything from working more productively to enjoying media more.
Gigabit Speeds
Experience speeds up to 1000 Mbps for Gigabit-enabled devices up to 10 times faster than standard Ethernet. Perfect for graphics, multimedia, and other applications that have to move large files across the network quickly.
Automated Optimization
Five auto-sensing ports designed to automatically deliver optimal Ethernet or Gigabit speeds for each connected device and eliminate the need for MDI/MDI-X crossover cables. Flow Control Blocking Prevention technology designed to help keep lower-speed traffic from bogging down high-speed transmissions.
Reliability
Connectivity you can count on. Address Learning and Aging and Data Flow Control designed to help ensure better data flow and fewer transmission errors.
Desktop for Workgroups
Replace your current hub-based Ethernet network with the switching power of this compact unit and improve your data traffic efficiency.
Tech Specs
- Model: Number EG005W
- Standards: IEEE 802.3, 802.3u, 802.3x, 802.3ab
- Ports: 5 RJ-45 10/100/1000 Mbps ports
- Cabling Type: Category 5e Recommended
- LEDs: Power, Link/Act, Speed, FDX
Key Features
- 5 RJ-45 10/100/1000Mbps auto-sensing half/full duplex switched ports
- All ports suppport auto MDI/MDI-X cable detection
- Fully compliant with IEEE 802.3, 802.3u, 802.3x, 802.3ab
- Non head-of-line blocking architecture
- Full-duplex IEEE 802.3x low control and half-duplex backpressure with intelligent port-based congestion detection and broadcast rate control
Environmental Details
- Dimensions 7.32" x 1.89" x 6.06" (186 x 48 x 154 mm)
- Weight 1.1 lbs (500 g)
- Power External Power Supply 12V DC, 2A
- Input 110 V AC Consumption 18W
- Certiication FCC Part 15 Class A
- Operating Temp. 32 to 122F (-1 to 50C)
- Storage Temp. -40 to 158F (-20 to 70C)
- Operating Humidity 10 to 95% Noncondensing
- Storage Humidity 5 to 95% Noncondensing
Package Contents
- Gigabit 5-Port Workgroup Switch
- AC Power adapter
- Registration card
- User Guide
Minimum Requirements
- 200Mhz or Faster Processor
- 64MB RAM Recommended
- Ethernet or Gigabit Network Ada
- Cat5e Ethernet Network Cable
