Part Number:
132329
(?) Brand:
Manuf No:
R5970-P2D2G
R5970P2D2G
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
All stock codes associated to this product
R5970P2D2G, R5970-P2D2G, 1083674, 816909066838


Key Messges

  • Over voltage function of GPU
    MSI's own "Afterburner" overclocking software that allows the user to adjust both the voltage and overclocking settings for better performance.
  • 40nm Dual GPUs + 2GB GDDR5 Memory
    Dual 40nm 5970 GPUs + 2GB GDDR5 memory provides the greatest performance on the planet.
  • DirectX 11 & OpenCL support
    -Support the latest DirectX 11/Shader 5.0 and OpenGL 3.2 graphical standards.
    -Support OpenCL (Open Computer Language) to execute parallel computing by GPU.
  • ATi Eyefinity Technology
    - Support up to 3 monitor outputs simultaneously and independently.(one of the outputs must be DisplayPort.)
    - Maximum 3 * 2560*1600 resolution.
    - Improve work productivity and provide better gaming experience.


Military Class Concept

  • Hi-c CAP(Highly-Conductive Capacitor)
    -Tantalum Core
    -Rare metal, incredibly stable
    -Extremely high conductivity
    -15x Less leakage
    -Stabilize GPU power, better overclocking
    -Used on space shuttles and satellites



  • Solid State Choke
    - Pure Iron Core
    - New generation, form-in-one choke
    - No buzz noise
    - Higher maximum current output
    - Better protection of power surge
    - Designed for overclocking
  • Solid Capactior
    - Aluminum Core
    - 10 years ultra long lifetime
    - No explosion
    - Extreme low ESR
    - Lower Temperature
    - High efficiency


Features

Afterburner
Afterburner
co-development by MSI and Rivatuner, MSI releases the ultimate graphics card utility Afterburner. This utility enables all MSI graphics cards users to boost performance and to monitor all kinds of critical information in real-time. Afterburner is a completely free utility which is compatible with almost all MSI graphics cards.
MSI Solid Capacitor Graphic Cards
MSI Solid Capacitor Graphic Card
MSI Graphics Card products utilities high quality solid capacitor. For the gamers and high-end users, this feature not only means that product has better quality components within, but also provide much stronger support while users want to engage in hard-core tuning.

DOT Express (Dynamic Overclocking Technology Express)
MSI DOT Express Technology is the most advanced Dynamic Overclocking Technology Express enabling supreme overclocking, cooling and de-noise performance. It is an advanced overclocking engine, designed to deliver up to 10% extra performance and greatly enhances the synchronized GPU & DDR performance.
HDMI + DVI Output
HDMI + DVI Output
HDMI and DVI are the most comprehensive used interfaces for high definition video display. MSI adopts two interfaces to provide a complete output solution for users to enjoy the latest HD video such as blu-ray movie.

Live Update 4
MSI Live Update 4 is a single utility software that automatically checks BIOS, driver and utility updates and installs for you , which can save your time for searching and lower the risk while updating.
MSI Advanced Live Update Online
MSI Live Update online

MSI Live Update online is designed to automatically download and update the BIOS and driver when theres a new version online. It helps reduce the risk of getting the wrong file and minimize the trouble of searching the files from MSI website.

HDMI convertible output
Dual-link DVI convertible output supports Video/Audio signal integration through DVI to HDMI interface, which drivers resolution of a digital display up to 1920x1200 or higher.
HDMI Support
MSI graphics cards offer the HDMI functionality to provide access to premium digital content. HDMI enables gaming enthusiasts to seamlessly connect to their LCD monitor to bring the ultimate multimedia experience. (Only 1 single HDMI cable is required while streaming audio/video data to flat-panel display devices, such as Plasma/LCD TVs, or projector.)

HDCP Support
The HDCP provides a robust, cost-effective and transparent method for transmitting and receiving digital entertainment similar to DVI/HDMI-compliant digital displays. HDCP encrypts the date transmitted between the DVI/HDMI connector on the graphics adapter and the display.
Blu-ray and HD DVD Support
Both support the latest specifications of Blu-ray and HD DVD(High Definition DVD). It comes with the latest GPU and DDRIII superior processing performance in which users can easily enjoy the high-definition video of 1920x1080(1080p/i).

Meet RoHS regulations
MSI products are the first to be in conformity of the EUs RoHS(Restriction of Hazardous Substances) regulations, reducing heavy metals and toxic materials in the products. This is an effort made for the Earth, and essentially for a clean future.


Specifications


Video Output Function

  • Mini DisplayPort x 1
  • Dual-link DVI x 2
  • VGA (via DVI to D-Sub adaptor) x 2
  • HDMI (via DVI to HDMI adaptor) x 2



Bundle MSI developed software

  •  MSI VGA Driver
  • MSI Live Update Series (Live VGA BIOS & Live VGA Driver)
    Automatically online download & update VGA BIOS & Drivers, reduce the risk of getting the wrong files, and never have the trouble on web site searching.
  • MSI VIVID
    Vivid brings the easiest way to optimize graphic quality. Colorize your vision when browsing digital photos!!! Sharpen characters edge!!! Enhance contrast when playing game!!!
  • MSI Live
    MSI Live including all real time life information you need, such as Live MSI Product News, Live Daily Information, Live Personal Schedule Manager, Live Search and more.
  • MSI Live
  • Adobe Acrobat Reader
  • Microsoft  DirectX
  • Norton Internet Security 2008 60 days Trial
    -Blocks online identity theft by phishing Web sites
    -Detects and eliminates spyware
    -Removes viruses and Internet worms automatically
    -Protects against hackers


Product Accessories










MSI Reminds You...
The accessories will probably be different according to the different selling areas of product models. For details of accessories, please refer to the descriptions on the product package.




Graphics Engine ATI Radeon HD 5970
Bus Standard PCI Express x16 2.1
Memory Type DDR5
Memory Size(MB) 2048
Memory Interface 512bits (256 bits x 2)
Core Clock Speed(MHz) 725
Memory Clock Speed(MHz) 4000
Memory Bandwidth(GB/sec) N/A
Texture Fill Rate(billion/sec) N/A
DVI Output 2
D-SUB Output 2(via DVI to D-Sub adaptor)
TV-Output N/A
HDMI-Output 2(via DVI to HDMI adaptor)
VIVO(Video-in/out) N/A
HDTV Support N/A
HDCP Support Y
HDMI Support Y
Dual-link DVI Y
Display Ouput(Max Resolution) 3x 2560x1600
RAMDACs 400
DirectX Version Support 11
OpenGL Version Support 3.2
CrossFire Support Y
SLI Support N/A
3-way SLI N/A
HyperMemory Tech. N/A
TurboCache tech. N/A
GPU Features Microsoft DirectX 11 Support
ATI Eyefinity Technology
ATI Stream Technology
40 nm Process Technology
Advanced GDDR5 Memory Technology
2nd Generation TeraScale Engine
Microsoft Windows 7 support
ATI CrossFireX Technology
Enhanced Anisotropic Filtering
Accelerated Video Transcoding
HDMI 1.3 Support
Dolby TrueHD and DTS-HD Master Audio Support
ATI PowerPlay Technology Enhanced Support for GDDR5 memory
ATI Avivo Technology Enhanced Unified Video Decoder 2 (UVD 2)

All brand name & products are registered trademarks of their respective companies.
All Chipset specs are derived from ATI data sheet. For your reference only.

No additional files, specification sheets, guides or documentation found for product.

Warranty: 3 Years

Full manufacturers warranty details are available at the manufacturers (MSI) web site.
