IMG 1 of 1
1 image(s) are available
for this product
Note: physical product may
vary from images displayed.
No Longer Available

Part Number:
136066
Usually Ships:
No Longer Available More info
(?) Brand:
Manuf No:
R5450-MD1GH
R5450MD1GH
Shipping Weight:
1 KG (Includes product packaging)


Key Messges

  • MSI Afterburner Overclocking Utility
    -Support 2D/3D customized profile
    -Support CrossFireX mode
  • All Solid Capacitors
    -10 years ultra long lifetime (under full load).
    -Lower temperature and higher efficiency.
    -Aluminum core without explosion.
  • Native HDMI Output
    -Support both 1080P HD movie playback and 7.1 Channel audio transmission.
  • Low Profile Design
    -Extra Large heatsink for the best heat dissipation and zero db noise.
    -Work perfect with slim or smaller system.


Features

Afterburner
Afterburner
co-development by MSI and Rivatuner, MSI releases the ultimate graphics card utility Afterburner. This utility enables all MSI graphics cards users to boost performance and to monitor all kinds of critical information in real-time. Afterburner is a completely free utility which is compatible with almost all MSI graphics cards.
ATI Stream
Perform tasks on a PC faster with ATI Stream technology, speed up demanding everyday applications and get more done in less time.

DirectX 11
The first fully Microsoft DirectX 11-compatible GPUs in their class, the ATI Radeon HD 5000 Series are designed to deliver unbelievable HD gaming performance for the latest games and DirectX 11 applications so you can dominate the competition.
MSI Solid Capacitor Graphic Cards
MSI Solid Capacitor Graphic Card
MSI Graphics Card products utilities high quality solid capacitor. For the gamers and high-end users, this feature not only means that product has better quality components within, but also provide much stronger support while users want to engage in hard-core tuning.

DOT Express (Dynamic Overclocking Technology Express)
MSI DOT Express Technology is the most advanced Dynamic Overclocking Technology Express enabling supreme overclocking, cooling and de-noise performance. It is an advanced overclocking engine, designed to deliver up to 10% extra performance and greatly enhances the synchronized GPU & DDR performance.
HDMI + DVI Output
HDMI + DVI Output
HDMI and DVI are the most comprehensive used interfaces for high definition video display. MSI adopts two interfaces to provide a complete output solution for users to enjoy the latest HD video such as blu-ray movie.

Live Update 4
MSI Live Update 4 is a single utility software that automatically checks BIOS, driver and utility updates and installs for you , which can save your time for searching and lower the risk while updating.
MSI Advanced Live Update Online
MSI Live Update online

MSI Live Update online is designed to automatically download and update the BIOS and driver when theres a new version online. It helps reduce the risk of getting the wrong file and minimize the trouble of searching the files from MSI website.

HDMI convertible output
Dual-link DVI convertible output supports Video/Audio signal integration through DVI to HDMI interface, which drivers resolution of a digital display up to 1920x1200 or higher.
HDMI Support
MSI graphics cards offer the HDMI functionality to provide access to premium digital content. HDMI enables gaming enthusiasts to seamlessly connect to their LCD monitor to bring the ultimate multimedia experience. (Only 1 single HDMI cable is required while streaming audio/video data to flat-panel display devices, such as Plasma/LCD TVs, or projector.)

HDCP Support
The HDCP provides a robust, cost-effective and transparent method for transmitting and receiving digital entertainment similar to DVI/HDMI-compliant digital displays. HDCP encrypts the date transmitted between the DVI/HDMI connector on the graphics adapter and the display.
Blu-ray and HD DVD Support
Both support the latest specifications of Blu-ray and HD DVD(High Definition DVD). It comes with the latest GPU and DDRIII superior processing performance in which users can easily enjoy the high-definition video of 1920x1080(1080p/i).

Meet RoHS regulations
MSI products are the first to be in conformity of the EUs RoHS(Restriction of Hazardous Substances) regulations, reducing heavy metals and toxic materials in the products. This is an effort made for the Earth, and essentially for a clean future.


Specifications


Video Output Function

  • Dual-link DVI x1
  • D-Subx1
  • HDMI x 1



Bundle MSI developed software

  •  MSI VGA Driver
  • MSI Live Update Series (Live VGA BIOS & Live VGA Driver)
    Automatically online download & update VGA BIOS & Drivers, reduce the risk of getting the wrong files, and never have the trouble on web site searching.
  • MSI VIVID
    Vivid brings the easiest way to optimize graphic quality. Colorize your vision when browsing digital photos!!! Sharpen characters edge!!! Enhance contrast when playing game!!!
  • MSI Live
    MSI Live including all real time life information you need, such as Live MSI Product News, Live Daily Information, Live Personal Schedule Manager, Live Search and more.
  • MSI Live
  • Adobe Acrobat Reader
  • Microsoft  DirectX
  • Norton Internet Security 2008 60 days Trial
    -Blocks online identity theft by phishing Web sites
    -Detects and eliminates spyware
    -Removes viruses and Internet worms automatically
    -Protects against hackers



Specifications

Graphics Engine ATI Radeon HD 5450
Bus Standard PCI Express x16 2.1
Memory Type DDR3
Memory Size(MB) 1024
Memory Interface 64 bits
Core Clock Speed(MHz) 650
Memory Clock Speed(MHz) 1600
Memory Bandwidth(GB/sec) N/A
Texture Fill Rate(billion/sec) N/A
DVI Output 1
D-SUB Output 1
TV-Output N/A
HDMI-Output 1
VIVO(Video-in/out) N/A
DisplayPort N/A
HDTV Support N/A
HDCP Support Y
HDMI Support Y
Dual-link DVI Y
Display Ouput(Max Resolution) 2560x1600
RAMDACs 400
DirectX Version Support 11
OpenGL Version Support 3.2
CrossFire Support Y(SW)
SLI Support N/A
3-way SLI N/A
HyperMemory Tech. N/A
TurboCache tech. N/A
Card Dimension(mm) 167.5 x 69 x 32mm
Weight 207g
GPU Features Microsoft DirectX 11 Support
ATI Eyefinity Technology
ATI Stream Technology
40 nm Process Technology
DDR3/ DDR2 Memory Interface supported
292 million 40nm Transistors
OpenGL 3.2 Supported
Image Quality enhancement technology
Microsoft Windows 7 support
Enhanced Anisotropic Filtering
Accelerated Video Transcoding
HDMI 1.3 Support
Dolby TrueHD and DTS-HD Master Audio Support
ATI PowerPlay Technology
ATI AvivoTM Technology Enhanced Unified Video Decoder 2 (UVD 2)

All brand name & products are registered trademarks of their respective companies.
All Chipset specs are derived from ATI data sheet. For your reference only.
