| System
| CPU: TI DM365 SoC
Flash: 128MB
RAM: 256MB
Embedded OS: Linux 2.6 |
| Lens
| f = 3.6 mm
F 1.8
Board lens
IR corrected
Removable IR-cut filter for day & night function
|
| Angle of View
| 56 (horizontal)
41 (vertical)
71 (diagonal)
|
| Shutter Time
| 1/5 ~ 1/25,000 sec |
| Image sensor
| 1/4" CMOS in 1280 x 800 Resolution |
| Minimum Illumination
| 0 Lux @ F1.8 ( IR LED on )
|
| IR Illuminators
| IR LED*12
Built-in IR illuminators, Effective up to 15 meter |
| Video
| Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to Up to 30/25 fps at 1280x800
MPEG-4: Up to Up to 30/25 fps at 1280x800
MJPEG: Up to Up to 30/25 fps at 1280x800
|
| Image Settings
| Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Automatic, manual or scheduled day/night mode
Supports privacy masks
|
| Networking
| 10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management
| Triple-window video motion detection
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
|
| On-board Storage
| MicroSD/SDHC card slot
Stores snapshots and video clips
|
| Security
| Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users
| 10 clients on-line monitoring at the same time |
| Dimensions
| : 60mm x 170 mm |
| Weight
| Net: g |
| Power
| 12V DC
24V AC
Power consumption: Max. 4 W
802.3af compliant Power-over-Ethernet |
| Housing
| Weather-proof IP66-rated housing
|
| Approvals
| CEC-TickFCCLVDVCCI |
| Operating Environments
| Temperature: -20 ~ 50 C (-4 ~ 122 F )
Humidity: 90%
|
| Viewing System Requirements
| OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance
| Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications
| SDK available for application development and system integration |
| Warranty
| 12 months |
