Ultrastar 15K600



300GB, 450GB & 600GB
3.5-INCH ENTERPRISE HARD DRIVE

  • Mission-Critical Performance 15,000 RPM access to data

  • High Capacity Up to 600GB of storage

  • Data Security Hardware-based encryption models

The Ultrastar 15K600 combines ultimate performance with high capacity in a single drive, storing up to 600GB of data while spinning at 15,000 RPM. That amounts to a capacity growth of 33% over its predecessor to keep pace with digital data growth and improve space efficiency in todays data centers. At the same time, sequential performance increased by 23% compared to prior generation to keep data moving faster. The 64MB cache buffer is the largest in the industry in its class. The 6Gb/s Serial Attached SCSI (SAS) and 4Gb/s Fibre Channel Arbitrated Loop (FCAL) interfaces support the reliability required in the most demanding enterprise computing environments like on-line transaction processing, intensive data analysis, multi-user applications and data warehousing.

Highlights
600GB capacity will store most everything
Spinning at 15,000 RPM for mission-critical performance
FCAL & SAS interfaces for reliable data throughput
Advanced Power Management optimizes power consumption
64MB cache buffer largest in the industry
Self-encrypting models conform to TCGs Enterprise specification

Applications / Environments
Business & online transaction processing
Internet, file sharing and email
Decision support & RAID
NAS, SAN and enterprise-class servers
High performance computing and other applications requiring 24x7
availability

Specifications

Model(s) HUS156060VLS600
HUS156060VLS601
HUS156060VLF400
HUS156060VLF401
HUS156045VLS600
HUS156045VLS601
HUS156045VLF400
HUS156045VLF401
HUS156030VLS600
HUS156030VLS601
HUS156030VLF400
HUS156030VLF401
Interface 6Gb/s SAS / 4Gb/s FCAL
Capacity (GB) 600 450 300
Data Heads (physical) 8 6 4
Performance
Data buffer (MB) 64
Rotational Speed (RPM) 15000
Latency Average (ms) 2
Interface transfer rate (MB/sec, max) 600 / 400
Sustained transfer rate (MB/sec, typ.) 198 to 119
Seek Time (read, ms, typical) 3.4
Reliability
Error Rate (non-recoverable, bits read) 1 in 10^16
MTBF (M hours) 1.6
Availability (hrs/day x days/wk) 24x7
Acoustics
Idle (Bels) 3.7
Power
Requirement +5 VDC (+/5%)
+12 VDC (+/5%)
Operating (W, typical) 16.6 14.4 13.2
Unload idle (W) 10.7 9.2 7.7
Physical size
Z-height (mm) 25.8
Dimensions (width x depth, mm) 101.6 x 146.2
Weight (g, max) 750
Environmental (operating)
Ambient temperature 5 to 55C
Shock (half-sine wave) 30G (2ms)
Vibration 1.5Gm all axes
Environmental (non-operating)
Ambient temperature -40 to 70C
Shock (half-sine wave) 250G (2ms)
Vibration 2.0G, all axes

Capacity GB - One GB is equal to one billion bytes when referring to hard drive
capacity. Accessible capacity may be less.
Data Buffer MB - Portion of buffer capacity used for drive firmware
Seek Time - Excludes command overhead
MTBF - MTBF target is based on a sample population and is estimated by statistical measurements and acceleration algorithms under median operating conditions. MTBF ratings are not intended to predict an individual drives reliability. MTBF does not constitute a warranty.
