On/Off Charge Support
GIGABYTE On/Off Charge technology that enables faster iPhone, iPad and iPod Touch charging. A derivative of GIGABYTE's highly acclaimed 3x USB Power feature, On/Off Charge technology allows iPhone, iPad and iPod touch devices to draw more current from GIGABYTE motherboard USB ports than standard USB ports allow, with the added benefit that the PC can be on, in standby mode or even off...more
*Due to certain mobile phone limitations, users may need to connect the mobile phone to their PC before the PC enters S4/S5 mode to enable a quick charge from non On/Off Charge USB ports. Charging results may vary by model.
AMD 880G 3D Graphics Performance Upgrade- up to 3DMark 2006 3000 marks!!
The 3DMark 2006 is a benchmark software which is from Futuremark Corporation and generally used on analyzing a PC performance of DirectX 3D visualization, especially a valuable guideline for gaming users as reference.
3DMark06 2868 marks on 880G system configuration
AMD PhenomII X4 965 (OC), GPU OC 1124MHz, 4GB DDR3-1600(OC), Win7-32bit, 3DMark06 (1280x1024)
* 3000+ marks in 3DMark06 was achieved by overclocking.
* Please be aware that GIGABYTE's product warranty does not cover damages caused by overclocking.
ATI Hybrid Graphics Technology support
Experience the advanced ATI Hybrid Graphics Technology, which is including ATI Hybrid CrossFireX, ATI SurroundView, and ATI PowerPlay with Windows 7, Vista and XP supported. With combination of onboard GPU and a single VGA cards GPU*, ATI Hybrid CrossFireX can bring remarkable display performance on AMD platform, and also further to increase your overall system value. ATI SurroundView allows 4 or more monitors support at once and also ATI PowerPlay enables power saving profiles to help reduce power consumption and further resulting in reduced system temperatures and fan noise.
* Please use ATI Hybrid CrossFireX certified DX11 VGA card (i.e., ATI Radeon HD 5450, etc.).
GIGABYTE innovative technology- Easy Energy Saver
Featuring an advanced proprietary software design, GIGABYTE Easy Energy Saver is able to dynamically adjust CPU power depending on workload, delivering just the right amount of power needed for the task. Coupled with AMDs highly efficient 45nm AM3 CPU, the Easy Energy Saver is able to provide exceptional levels of power savings and enhanced power efficiency without sacrificing computing performance.
HDMI 1.3* certification, support Full HD 1080P
HDMI is able to provide up to 5Gb/s video transmitting bandwidth and multi-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. GA-880GMA-UD2H has obtained the latest HDMI 1.3* certification, able to support Full HD 1080p multi-media and HDCP (High-bandwidth Digital Content Protection) which allowing Blu-ray/ HD DVD and other protected contents playback.
* HDMI 1.3 certified in video spec only.
Norton Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down. It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.
ErP Lot 6 support
The ErP (as known as Energy-Related Products Directive) is part of new European Union's environment regulations. ErP established is based on the concern of environmental issues regards electronic devices been gained popularity and how to improve energy efficiency for better and greener life. GIGABYTE presents standard motherboards to help you effectively improving system performance and saving more energy.
CPU
- Support for Socket AM3 processors: AMD Phenom II processor / AMD Athlon II processor
Hyper Transport Bus
- 5200 MT/s
Chipset
- North Bridge: AMD 880G
- South Bridge: AMD SB850
Memory
- 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (Note 1)
- Dual channel memory architecture
- Support for DDR3 1800(OC)/1333/1066 MHz memory modules (Note 2)
Onboard Graphics North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port (Note 3)(Note 4)
- 1 x HDMI port (Note 4)
Audio
- Realtek ALC892 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for Dolby Home Theater
- Support for S/PDIF In/Out
- Support for CD In
LAN
- 1 x Realtek 8111D chip (10/100/1000 Mbit)
Expansion Slots
- 1 x PCI Express x16 slot, running at x16 (PCIEX16) (Note 5)
- 1 x PCI Express x16 slot, running at x4 (PCIEX4) (Note 5)
- 1 x PCI Express x1 slot (All PCI Express slots conform to PCI Express 2.0 standard.)
- 1 x PCI slots
Multi-Graphics Technology
- Support for ATI Hybrid CrossFireX technology
Storage Interface South Bridge:
- 5 x SATA 6Gb/s connectors 6 supporting up to 5 SATA 6Gb/s devices
- 1 x eSATA 6Gb/s connectors on the back panel supporting up to 1 SATA 6Gb/s device
- Support for SATA RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
JMicron JMB368 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8720 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB South Bridge:
- Up to 10USB 2.0/1.1 ports (4 on the back panel, 6 via the USB brackets connected to the internal USB headers)
NEC D720200F1 chip:
- Up to 2 USB 3.0 ports on the back panel
IEEE 1394 T.I. TSB43AB23 chip:
- Up to 2 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x floppy disk drive connector
- 1 x IDE connector
- 5 x SATA 6Gb/s connectors
- 1 x CPU fan header
- 1 x system fan header
- 1 x front panel header
- 1 x front panel audio header
- 1 x CD In connector
- 1 x S/PDIF In/Out header
- 1 x IEEE 1394a header
- 3 x USB 2.0/1.1 headers
- 1 x serial port header
- 1 x clearing CMOS jumper
Back Panel Connectors
- 1 x PS/2 keyboard port or PS/2 mouse port
- 1 x D-Sub port
- 1 x DVI-D port (Note 3)(Note 4)
- 1 x HDMI port (Note 4)
- 1 x optical S/PDIF Out connector
- 1 x IEEE 1394a port
- 4 x USB 2.0/1.1 ports
- 1 x eSATA 6Gb/s connector
- 2 x USB 3.0/2.0 ports
- 1 x RJ-45 port
- 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
- ITE IT8720 chip
H/W Monitoring
- System voltage detection
- CPU/System temperature detection
- CPU/System/Power fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control (Note 6)
BIOS
- 2 x 8 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune (Note 7)
- Support for Easy Energy Saver
- Support for Smart Recovery
- Support for Auto Green
- Support for On/Off Charge
- Support for Q-Share
Bundle Software
- Norton Internet Security (OEM version)
Operating System
- Support for Microsoft Windows 7/ Vista/ XP
Form Factor
- ATX Form Factor; 30.5cm x 24.4cm
Note (Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) To reach DDR3 1800MHz or above, you must install two memory modules and install them in the DDR3_3 and DDR3_4 memory sockets.
(Note 3) The DVI-D port does not support D-Sub connector by adapter.
(Note 4) Simultaneous output for DVI-D and HDMI is not supported.
(Note 5) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. The PCIEX4 slot shares bandwidth with the PCIEX16 slot. When PCIEX4 is populated with a x4 card, the PCIEX16 slot will operate at up to x4 mode.
(Note 6) Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install.
(Note 7) Available functions in EasyTune may differ by motherboard model. Remark
- Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- Most hardware/software vendors no longer offer support for Win9X/ME. If drivers are available from the vendors, we will update them on the GIGABYTE website.
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
