PCI Case CLM-2168-20 - 20U Cabinet (W 600x D 800x H 1000mm)

IMG 1 of 1
No Longer Available
Part Number:
143957
(?) Brand:
PCI Case
Manuf No:
CLM-2168-20
CLM216820
Shipping Weight:
35 KG (Includes product packaging)
Estimate Shipping
Date Added:
31/5/2010
Details Files Finance Images & Video
All stock codes associated to this product
CLM216820, CLM-2168-20
20U Cabinet (W 600x D 800x H 1000mm)

  • Material: Cabinet frame of extrude aluminium sections.Front and rear door, side panels, top, bottom plates and plinth of sheet steel.
  • Standard Accessories:
    • Front Door:Glazed & vented sheet steel door
    • Rear panel: Vented sheet steel door
    • Side panel: Side panels with quick-release fastener
    • Roof: Flat roof plate with cutout & 3 cable entries
    • Mounting Angle: S-shaped mounting angles (attach to frame)
  • Color: Black and White
  • Plinth : Castors; Leveling feet
  • Optional Accessories:
    • Fan panel : Fan panel with 3 fans, up to 8 fans

Model
U
SU

Width (mm)
Height (mm)
Depth (mm)
Clear Height(mm)
CLM-2168-11

11
19
600
600
800
501
CLM-2168-15
15
26
600
800
800
701
CLM-2168-20
20
35
600
1000
800
901
CLM-2168-24
24
42
600
1200
800
1101
CLM-2168-29
29
51
600
1400
800
1301
CLM-2168-33
33
58
600
1600
800
1501
CLM-2168-38
38
67
600
1800
800
1701
CLM-2168-42
42
74
600
2000
800
1901
CLM-2168-47
47
83
600
2200
800
2101
CLM-2169-20
20
35
600
1000
900
901
CLM-2169-42
42
74
600
2000
900
1901

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.
