System |
CPU: TI DM365 SoC Flash: 128MB RAM: 256MB Embedded OS: Linux 2.6 |
Lens |
f=3.6 mm F 1.8 Board lens Fixed Removable IR-cut filter for day & night function
|
Angle of View |
56 (horizontal) 41 (vertical)
|
Shutter Time |
1/5 ~ 1/25,000 sec |
Image sensor |
1/4" CMOS in 1280x800 Resolution |
Minimum Illumination |
0 Lux / F1.8 ( IR LED on )
|
IR Illuminators |
IR LED*8 Built-in IR illuminators, Effective up to 10 meter |
Video |
Compression: H.264, MPEG-4 & MJPEG Streaming: Simultaneous multiple streams H.264 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 multicast streaming MJPEG streaming over HTTP or HTTPS Supports activity adaptive streaming for dynamic frame rate control Supports 3GPP mobile surveillance Frame rates: H.264: Up to 30/25 fps at 1280x800 MPEG-4: Up to 30/25 fps at 1280x800 MJPEG: Up to 30/25 fps at 1280x800
|
Image Settings |
Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure AGCAWBAES Automatic, manual or scheduled day/night mode Supports privacy masks BLC (Backlight compensation)
|
Networking |
10/100 Mbps Ethernet, RJ-45 ONVIF support Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
Alarm and Event Management |
Triple-window video motion detection One D/I and one D/O for external sensor and alarm Event notification using HTTP, SMTP, or FTP Local recording of MP4 files Tamper Detection
|
On-board Storage |
MicroSD/SDHC card slot Stores snapshots and video clips
|
Security |
Multi-level user access with password protection IP address filtering HTTPS encrypted data transmission 802.1X port-based authentication for network protection
|
Users |
10 clients on-line monitoring at the same time |
Dimensions |
: 110mm x 91 mm Cable length: 480 mm Cable diameter: 7.8 mm; Ring: 24 mm |
Weight |
Net: 479 g |
LED Indicator |
System power and status indicator System activity and network link indicator
|
Power |
12V DC Power consumption: Max. 4.5 W 802.3af compliant Power-over-Ethernet (Class 2)
|
Approvals |
CEC-TickFCCLVDVCCI |
Operating Environments |
Temperature: 0 ~ 50 C (32 ~ 122 F ) Humidity: 90%
|
Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7 Browser: Mozilla Firefox, Internet Explorer 6.x or above Cell phone: 3GPP player Real Player: 10.5 or above Quick Time: 6.5 or above |
Installation, Management, and Maintenance |
3-axis mechanism for flexible ceiling and wall mount installation Camera angle adjustment: Pan range: 350 Tilt range: 85 Rotate range: 350 Installation Wizard 2 32-CH central management software Supports firmware upgrade
|
Applications |
SDK available for application development and system integration |
Warranty |
12 months |
