ATEN RS-232 Parallel Bi-directional Converter

IMG 1 of 1
No Longer Available
Part Number:
153910
(?) Brand:
ATEN
Manuf No:
SXP325A-AT-U
SXP325AATU
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
SXP325AATU, SXP325A-AT-U, SXP325A, SXP-325A
Aten RS232/Parallel Bidirectional Converter

The SXP325A is an interface converters that allows Centronics and RS-232 devices to communicate with each other (a computer with an RS-232 output to a Centronics Parallel printer, for example). The unit is reversable enabling you to convert from serial to parallel or parallel to serial. The SXP325A is configured with 512 KB of memory allowing it to serve as a printer buffer. These two way converters provide a DB-25 RS-232C (DCE) compatible connector, and a C-36 Centronics connector. The serial baud rate is from 1200 to 115200 bps. (selectable by DIP Switch). The parallel interface speed for the SXP325A, it is 1.5 MB/sec. The units support both hardware and software (XON/XOFF) handshaking. Setup is extremely easy. All that is involved is setting the DIP Switch and connecting the cables.

Features
  • DIP Switch for Direction Setting
  • Serial baud rate 1200 to 115200 bps (DIP switch selectable) DB25 (DCE) to Centronics-36 (C36) Parallel Interface 1.5 MB/sec.
  • Built In Buffer for Efficient Operation (512KB)
  • Easy Installation Compact Size

SXP325

Specification :
Unit Dimensions
Width 2.5 in. (6.4 cm)
Height 4.0 in. (10.2 cm)
Depth 1.0 in. (2.5 cm)
Unit Package Dimensions
Width 9..375 in.
Height 6.25 in.
Depth 2.25 in.
Master Carton
Width 13.25 in.
Height 13.5 in. (34.3 cm)
Depth 20 in. (50.8 cm.)
Master Carton Qty. 20
Weight
Master Carton Wt. 20.74 lb.
Unit Pack Wt. 0.94 lb.

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.
