System |
CPU: TI DM365 SoC Flash: 128MB RAM: 128MB Embedded OS: Linux 2.4 |
Pan/Tilt/Zoom |
Pan range: 360 Tilt range: -10 ~ 190 12x optical zoom Pan speed: 0.1 ~ 300/sec Tilt speed: 0.1 ~ 120/sec Auto pan mode Auto patrol mode
|
Lens |
12x optical zoom f=3.8 ~ 45.6 mm F 1.6 (wide) F 2.8 (tele) Focus range: wide 20 mm,tele 3000 mm ~ auto iris Removable IR-cut filter for day & night function
|
Angle of View |
1.7 ~ 55.8 (horizontal)
|
Shutter Time |
1/2, 1/1.5(SD8121) ~ 1/30,000 sec |
Image sensor |
1/4" SONY EXview HAD CCD in D1 Resolution |
Minimum Illumination |
0.1 Lux / F1.6 ( typical ) in 0.01 Lux / F1.6 ( B/W ) |
Video |
Compression: H.264, MPEG-4 & MJPEG Streaming: Simultaneous multiple streams H.264 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 multicast streaming MJPEG streaming over HTTP or HTTPS Supports activity adaptive streaming for dynamic frame rate control Supports 3GPP mobile surveillance Frame rates: H.264: Up to 30/25 fps at 720x480 (NTSC) /720x576 (PAL) MPEG-4: Up to 30/25 fps at 720x480 (NTSC) /720x576 (PAL) MJPEG: Up to 30/25 fps at 720x480 (NTSC) /720x576 (PAL)
|
Image Settings |
Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure AGCAWBAES Automatic, manual or scheduled day/night mode Supports privacy masks BLC (Backlight compensation) WDR(widedynamicrange) |
Audio |
Compression GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law Interface: External microphone input Audio output
Supports two-way audio via SIP protocol Supports audio mute
|
Networking |
10/100 Mbps Ethernet, RJ-45 ONVIF support Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
Alarm and Event Management |
Triple-window video motion detection 1 D/I & 4 D/O for external sensor and alarm Event notification using HTTP, SMTP, or FTP Local recording of MP4 files
|
On-board Storage |
SD/SDHC card slot Stores snapshots and video clips
|
Security |
Multi-level user access with password protection IP address filtering HTTPS encrypted data transmission 802.1X port-based authentication for network protection
|
Users |
10 clients on-line monitoring at the same time |
Dimensions |
: 131mm x 200 mm Cable length: 680 mm Cable diameter: 8 mm; Ring: 13.5 mm |
Weight |
Net: 1500 g |
Power |
12V DC Power consumption: Max. 11.4 W
|
Approvals |
CEC-TickFCCLVDVCCI |
Operating Environments |
Temperature: 0 ~ 40 C (32 ~ 104 F) Humidity: 90%
|
Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7 Browser: Mozilla Firefox, Internet Explorer 6.x or above Cell phone: 3GPP player Real Player: 10.5 or above Quick Time: 6.5 or above |
Installation, Management, and Maintenance |
Installation Wizard 2 32-CH central management software Supports firmware upgrade
|
Applications |
SDK available for application development and system integration |
Warranty |
24 months |
