CPU |
Intel Socket 1155 for Intel 2nd Generation Core i7 Processor/Core i5 Processor/Core i3 Processor/ Support Intel 32nm CPU Supports Intel Turbo Boost Technology 2.0 *The Turbo Boost Thchnology 2.0 support depends on the CPU types.
|
Chipset |
Intel H67(B3) Express Chipset |
Memory |
4 x DIMM, Max. 32 GB, DDR3 1333/1066 Memory Dual Channel memory architecture Supports Intel Extreme Memory Profile (XMP) * According to Intel SPEC, the Max. 32GB memory capacity can be supported with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available on the market. * Hyper DIMM support is subject to the physical characteristics of individual CPUs. Some hyper DIMMs only support one DIMM per channel. Please refer to Memory QVL for details. * Please refer to www.asus.com or user manual for Memory QVL.
|
Expansion Slots |
1 x PCIe 2.0 x16 [blue] (at x16 mode) 1 x PCIe 2.0 x16 [black] (at x4 mode, compatible with PCIe x1, x2 and x4 devices) 2 x PCI
|
VGA |
Multi-VGA output support: HDMI, DVI-D, RGB port Supports HDMI with max. resolution 1920 x 1200@60Hz Supports DVI with max. resolution 1920 x 1200@60Hz Supports RGB with max. resolution 2048 x 1536@75Hz Maximum shared memory of 1748 MB |
Multi-GPU Support |
Supports ATI Quad-GPU CrossFireX Technology |
Storage |
Intel H67(B3) Express Chipset 2 xSATA 6.0 Gb/s ports (gray) 4 xSATA 3.0 Gb/s ports (blue) Intel Rapid Storage Technology Support RAID 0,1,5,10 VIA VT6415 PATA controller 1 xUltraDMA 133/100 for up to 2 PATA devices
|
LAN |
Realtek 8111E Gigabit LAN controller |
Audio |
Realtek ALC892 8-Channel High Definition Audio CODEC - BD Audio Layer Content Protection - Supports Jack-Detection, Multi-streaming and Front Panel Jack-Retasking - Optical S/PDIF out port at mid-board & back I/O |
USB |
USB 3.0 controller: - 2 x USB 3.0/2.0 ports (blue, at the back I/O) Intel H67(B3) Express Chipset: - 14 x USB 2.0/1.1 ports (10 ports at mid-board, 4 ports at back panel)
|
ASUS Unique Features |
ASUS TurboV EVO - GPU Boost (without switch) - Auto Tuning* (adopt Fast Mode) - TurboV ASUS Power Design - 4+2 Phase Power Design ASUS Exclusive Features - MemOK! - AI Suite II - ASUS EFI BIOS EZ Mode featuring friendly graphics user interface ASUS Protect 3.0 Technology - ASUS EPU - Anti-Surge Protection - Low EMI Solution ASUS Quiet Thermal Solution - ASUS Fanless Design: Heat-sink solution - ASUS Fan Xpert ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 ASUS Q-Design - ASUS Q-Slot - ASUS Q-DIMM
|
Overclocking Features |
Precision Tweaker 2 - vCore: Adjustable CPU voltage at 190-step - iGPU: Adjustable iGPU voltage at 254-step - iGPU: Adjustable iGPU voltage at 190-step -vCCIO: Adjustable I/O voltage at 190-step - vDRAM Bus: AdjustableMemory voltage at 190-step - vPCH: AdjustableChipset voltage at 190-step - vCPU_PLL: AdjustableCPU & PCH PLLvoltage from 1.8V to 1.9V SFS (Stepless Frequency Selection) - BCLK/PEG frequency tuning from 80MHz up to300MHz at0.1MHz increment Overclocking Protection - ASUS C.P.R.(CPU Parameter Recall)
|
Back Panel I/O Ports |
1 x PS/2 Keyboard/Mouse Combo port 1 x DVI 1 x D-Sub 1 x HDMI 1 x LAN(RJ45) port(s) 2 x USB 3.0/2.0 ports (blue) 4 x USB 2.0/1.1 ports 1 x S/PDIF Out (Optical) 6 x Audio Jacks |
Internal I/O Connectors |
5 x USB 2.0/1.1 connector(s) support additional 10 USB ports 1 x MemOK! Button 1 x IDE connector 1 x TPM connector 2 x SATA 6.0Gb/s (gray) 4 x SATA 3.0Gb/s (blue) 1 x CPU Fan connector(s) (4-pin) 1 x Chassis Fan connector(s) (4-pin) 1 x Power Fan connector(s) (3-pin) 1 x S/PDIF Out connector 1 x 24-pin ATX Power connector 1 x 8-pin ATX 12V Power connector 1 x Front panel audio connector 1 x System Panel COM connector 1 x Clear CMOS jumper
|
BIOS |
32 Mb Flash ROM , EFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
|
Manageability |
WfM 2.0,DMI 2.0,WOL by PME,WOR by PME,PXE |
Accessories |
User's manual 1 x I/O Shield 1 x UltraDMA 133/100/66 cable 2 x SATA 6.0Gb/s cables
|
Support Disc |
Drivers Anti-virus software (OEM version) ASUS Update ASUS Utilities
|
Form Factor |
uATX Form Factor 9.6 inch x 9.6 inch ( 24.5 cm x 24.5 cm ) |
