Introducing a monitor that was built to stand the test of timeand dust. This Samsung LFD is durable and dust-resistant. Corner-sealing design, double-layer structure, and screw and user hole sealing add to its ruggedness. Make sure dirt and dust dont stand in the way of getting your message out.
Brighter lights, better picture.
With an intensely illuminated DID panel your message is always in the spotlight. Its high brightness and contrast level make the screen clear and readable in public. In fact, on average its 1.5 times as bright as TV screens. Plus with a low operating temperature this Samsung LFD will be completely reliable for years to come.
Twice the information, double the impact.
Whether your presentation requires a picture-in-picture configuration or a picture-by-picture arrangement, this Samsung LFD makes it possible. When one image just isnt enough, two video signals can be viewed simultaneously for maximum impact.
A video wall that lives up to your standards
Create the ultimate video wall with Samsung LFDs that cater to your needs. And because this LFD has an embedded video matrix processor, it supports 1 x 1 to 10 x 10 wall formats, allowing you to enjoy total convenience. Best yet, since they need no additional support, the possibilities are almost endless.
Upgrade effortlessly.
This Samsung LFD LFD makes upgrading firmware easy. The simple transmission is accomplished through an image file, using a DVI, HDMI or display port. Samsungs LFD LFD lets you perform upgrades effortlessly through a direct connection with your PC.
Save money, save space with built-in speakers.
Maximise your impact with a great picture and crisp audio. Your message will be heard loud and clear with built-in speakers. Youll save money when you eliminate the cost of purchasing separate speakers, and youll save valuable space as well.
Stay in the loop with DVI-out.
Enjoy superior picture quality with a DVI-out interface that lets you share content between multiple LFDs thanks to an easier-to-connect video matrix. LFDs used to have to be connected to the PC individually, but digital loop out allows you to connect them without connecting to a PC. Better yet, the digital loop out produces a single image without any loss of quality, and theres no need for a separate video signal distributor. Its easy to install and the most cost-effective way to connect multiple displays.
Choose the right view, landscape or portrait.
This Samsung LFD gives you the flexibility to display your image vertically or horizontallywhatever the situation calls for. With a pivot function that rotates the screen 90 degrees and the freedom to display presentations in portrait mode or advertisements in landscape mode, this makes for one versatile monitor.
A screen that wont shatter your digital dreams. (option)
When a monitor is displayed in public areas, things can happen. Thats why our LFD offers a specially-designed, optional protection glass. Scratch resistant and shatter-proof, it shields the panels surface from any damage so you can use it for years to come.
A great picture thats glare-free.
Whether you have a story to tell or a product to sell, its important that your image is crystal clear. This Samsung LFD delivers just thateven if your display is located in a brightly-lit environment. It eliminates any reflections that can disrupt your ads readability, keeping images smooth and visible.
Specifications
| Panel |
Diagonal Size |
46" |
| Type |
S-PVA (DID) |
| Resolution |
1920 x 1080 (16 : 9) |
| Pixel Pitch(mm) |
0.53025 (H) x 0.53025 (V) |
| Active Display Area(mm) |
1018.08 (H) x 572.67 (V) |
| Brightness(Typ.) |
700 cd/m |
| Contrast Ratio |
3000 : 1 : 00 |
| Viewing Angle(H/V) |
178 / 178 |
| Response Time(G-to-G) |
8 ms |
| Display Colors |
8 bit ~ 16.7 M |
| Color Gamut |
72% |
| Display |
Dynamic C/R |
10000 : 1 |
| H-Scanning Frequency |
30 kHz ~ 81 kHz |
| V-Scanning Frequency |
56 Hz ~ 85 Hz |
| Maximum Pixel Frequency |
148.5 MHz |
| Connectivity |
Input |
RGB |
Analog D-SUB, DVI-D, Display Port |
| Video |
CVBS, HDMI1, HDMI2, Component (D-sub 15 pin) |
| Audio |
RCA (L / R), Stereo mini Jack |
| Output |
RGB |
DVI-D (Loop-out) |
| Audio |
Stereo mini Jack |
| Power Out |
5 V (for SBB) |
| External Control |
RS232C (in / out), RJ45 |
| External Sensor |
Stero mini jack (IR in / out), mini USB (Ext. BR / IR sensor) |
| Power |
Type |
Internal |
| Power Supply |
AC 100 ~ 240 V ~ (+ / - 10%), 50 / 60 Hz |
| Power Consumption |
On Mode |
250 W (max) / 230 W (typ) |
| Sleep Mode |
less than 2 W |
| Off Mode |
less than 1 W |
| Mechanical Spec |
Dimension (mm) |
Set |
1049 x 603 x 118 mm |
| Package |
1155 x 733 x 325 mm |
| Weight (kg) |
Set |
24.5 kg |
| Package |
29.5 kg |
| VESA Mount |
600 x 400 mm |
| Stand Type |
Foot Stand (optional) |
| Operation |
Operating temperature: |
0C ~ 40C |
| Humidity |
10 ~ 80% |
| Feature |
Key |
Narrow Bezel |
| Special |
Lamp Error Detection, Anti Retention, Temperature Sensor, RS232C / RJ45 MDC, Plug and Play (DDC2B), PIP / PBP, Video Wall (10 x 10), Pivot Display, Button Lock, Digital Daisy Chain, Smart Scheduling, Smart F / W update |
| Certification |
Safety |
UL (USA) : UL 60950-1
CSA (Canada) : CSA C22.2 No. 60950-1
TUV (Germany) : EN60950-1
NEMKO (Norway) : EN60950-1
KC (Korea) : K60950-1
CCC (China) : GB 4943-2001
PSB (Singapore) : IEC60950-1
GOST (Russia) : IEC60950-1, EN55022
SIQ (Slovenia) : IEC60950-1, EN55022
PCBC (Poland) : IEC60590-1, EN55022
NOM (Mexico) : NOM-019-SCFI-1993
IRAM (Argentina) : IEC60950-1
SASO (Saudi Arabia) : IEC60950-1 |
| EMC |
FCC (USA) FCC Part 15, Subpart B class B
CE (Europe) EN55022, EN55024
VCCI (Japan) V-3 (CISPR22)
KCC (Korea) : KN22, KN24
BSMI (Taiwan) : CNS13438 (CISPR22)
C-Tick (Australia) : AS/NZS3548 (CISPR22)
CCC (China) : GB 9254-2008, GB 17625.1-2003 |
| Environment |
ENERGY STAR 5.0 (USA) |
| Accessories |
Included |
Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries, Panel Cover |
| Optional |
Stand |
STN-L3255D |
| Mount |
WMN5770D |
| Specialty |
CML500D (ceiling mount), STN-520WE (welcome Board) MID46-UX3, MID462K, MID462DS (SamsungID) CY-EBIS (ext.sensor) |
