| System |
CPU: Multimedia SoC |
| Lens |
f=3 ~ 9 mm
F 1.2 (wide)
F 2.1 (tele)
auto iris
Board lens
Removable IR-cut filter for day & night function
|
| Angle of View |
85.7~31.46 (horizontal)
73.16~25.4 (vertical)
99.82~39.67 (diagonal)
|
| Shutter Time |
1/5 ~ 1/32,000 sec |
| Image sensor |
1/3" CMOS in 1280x1024 Resolution |
| Minimum Illumination |
0.02 Lux / F1.2 ( typical )
0.001 Lux / F1.2 ( B/W ) |
| IR Illuminators |
IR LED*12
Built-in IR illuminators, Effective up to 15 meter |
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports ePTZ for data efficiency
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 60 fps @ 1280 x 720, Up to 30 fps @ 1280 x 1024
MPEG-4: Up to 25 fps @ 1280 x 1024
MJPEG: Up to 30 fps @ 1280 x 1024
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
|
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
External microphone input
Audio output
Supports two-way audio
Supports audio mute
|
| Networking |
10/100/1000 Mbps Gigabit Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
|
| On-board Storage |
MicroSD/SDHC card slot
Stores snapshots and video clips
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users |
10 clients on-line monitoring at the same time |
| Dimensions |
: 70mm x 186 mm
Cable length: 520 mm
Cable diameter: 7.2 mm; Max Connector: 14 mm |
| Weight |
Net: 805 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
|
| Power |
12V DC
24V AC
Power consumption: Max. 10 W
802.3af compliant Power-over-Ethernet (Class 3)
|
| Housing |
Weather-proof IP67-rated housing
|
| Approvals |
CEC-TickFCCLVDVCCI |
| Operating Environments |
Temperature: -20 ~ 50 C (-4 ~ 122 F )
Humidity: 90%
|
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
Mounting bracket w/ cable concealment
RS-485 interface for scanners, pan/tilts
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
36 months |
