| System |
CPU: Multimedia SoC |
| Lens |
f=1.27 mm
F 2.8
Board lens
Fixed
Removable IR-cut filter for day & night function
|
| Angle of View |
180
|
| Shutter Time |
1/5 ~ 1/32,000 sec |
| Image sensor |
1/2" CMOS in 2048x1536 Resolution |
| Minimum Illumination |
1.17 Lux @ F2.8 ( typical )
0.2 Lux @ F2.8 ( B/W ) |
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports ePTZ for data efficiency
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 15 fps at 1536x1536
MPEG-4: Up to 15 fps at 1536x1536
MJPEG: Up to 15 fps at 1536x1536
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
WDR enhanced |
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
Built-in microphone
External microphone input
Audio output
Supports two-way audio
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management |
Quintuple window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
|
| On-board Storage |
MicroSD/SDHC/SDXC card slot
Stores snapshots and video clips
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users |
10 clients on-line monitoring at the same time |
| Dimensions |
: 145mm x 52 mm
|
| Weight |
Net: 566 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
|
| Power |
12V DC
Power consumption: Max. 3.84 W
802.3af compliant Power-over-Ethernet (Class 3)
|
| Housing |
Weather-proof IP66-rated housing
Vandal-proof IK10-rated metal housing
|
| Approvals |
CEC-TickFCCLVDVCCIEN50155 |
| Operating Environments |
Temperature: -25C ~ 50C (-13F ~ 122F)
Humidity: 90% RH
|
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
36 months |
