System |
CPU: Multimedia SoC |
Camera Control |
PTZ camera control through RS-485 Supported devices and protocols: DynaDome / SmartDome, Pelco D, LiLin, Pelco P, Samsung scc643, and customized types Supports CGI command serial driver |
Video |
Compression: H.264, MPEG-4 & MJPEG Streaming: Simultaneous dual streams H.264 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MJPEG streaming over HTTP or HTTPS Supports activity adaptive streaming for dynamic frame rate control Supports 3GPP mobile surveillance Frame rates: H.264: Up to 30/25 fps @ 720 x 480 (NTSC) /720 x 576 (PAL) per channel, Up to 180 fps at D1 in total MPEG-4: Up to 30/25 fps @ 720 x 480 (NTSC) /720 x 576 (PAL) per channel, Up to 80 fps at D1 in total MJPEG: Up to 30/25 fps @ 720 x 480 (NTSC) /720 x 576 (PAL) per channel, Up to 240 fps at D1 in total
|
Image Settings |
Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure Supports privacy masks
|
Audio |
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law Interface: Audio output: Terminal block x 4 Audio input: up to 1Vrms, 3.5 m Phone Jack Supports two-way audio Supports audio mute
|
Networking |
10/100/1000 Mbps Gigabit Ethernet, RJ-45 ONVIF support Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
Alarm and Event Management |
Triple-window video motion detection 4 D/I & 4 D/O for external sensor and alarm Event notification using HTTP, SMTP, or FTP Local recording of MP4 files Tamper Detection
|
On-board Storage |
SD/SDHC card slot
|
Security |
Multi-level user access with password protection IP address filtering HTTPS encrypted data transmission 802.1X port-based authentication for network protection
|
Users |
10 clients on-line monitoring at the same time |
Dimensions |
Depth: 189mm Width: 153mm Height: 49.3mm
|
Weight |
Net: 800 g |
LED Indicator |
System power and status indicator System activity and network link indicator Local storage activity indicator
|
Power |
12V DC 24V AC Power consumption: Max. 24 W
|
Approvals |
CEC-TickFCCLVDVCCI |
Operating Environments |
Temperature: -10 ~ 50 C (14 ~ 122 F) Humidity: 20% ~ 80%
|
Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7 Browser: Mozilla Firefox, Internet Explorer 6.x or above Cell phone: 3GPP player Real Player: 10.5 or above Quick Time: 6.5 or above |
Installation, Management, and Maintenance |
RS-485: Half Duplex Installation Wizard 2 32-CH central management software Supports firmware upgrade
|
Applications |
SDK available for application development and system integration |
Warranty |
24 months |
