Provides HDMI, DVI-I and Dual Independent Display with full 1080p support to deliver the stunning full HD and 3D graphics for high-end users
Provides the high-capacity and high performance with RAID 0, 5 and 10 and also the most effective data protection to recover a hard drive failure with RAID 1, 5 and 10. The two sets of eSATA and two sets of SATA2 enable the full SATA interface speed outside the chassis, up to 3 Gb/s. In addition, SH67H3 maintain a high-speed storage interface with build-in four USB 3.0, seven USB 2.0 and SATA3 6Gpbs for optimal data access.
The 80 PLUS performance specification requires power supplies in computers and servers to be 80% or greater energy efficient. This makes an 80 PLUS certified power supply up to 33% more efficient than current power supplies. 300W high efficiency & energy saving power supply of SH67H3 is guaranteed by 80 PLUS BRONZE certification.
The technology allows heat from the CPU (the system's hottest component) transfers into a heatsink. The heat travels up a series of pipes and into an array of radiator fins screwed into the back of the chassis. A single, whisper-quiet fan mounted just behind this blows air through the fins, thus carrying the heat outside and away from the system. The SH67H3 XPC uses this patented cooling technology to provide the most stable and most optimal useful life.
Specifications
| FORM FACTOR |
Shuttle Form Factor |
| PROCESSOR |
Intel next grneration Core i7, Core i5 and Core i3 processor LGA1155 socket
95w max. Support
Note: Please choose processors with Intel HD Graphics technology to utilize on-board graphics function |
| CHIPSET |
Intel H67 |
| MEMORY |
DDR3 1333 MHz support RAM Socket * 4, Dual channels support
up to 16 GB total (4GB*4) |
| VGA |
Integrated in CPU |
| AUDIO |
Realtek ALC888
7.1 channel High Definition Audio
|
| ETHERNET |
Realtek RTL 8111E
10Mb/s,100Mb/s,1Gb/s operation
Support Wake-ON-LAN function
Support PXE function |
| STORAGE INTERFACE |
(2) SATA 3G
(2) SATA 6G |
| ONBOARD CONNECTORS |
(1) 4 Pin fan connector
(1) 3 Pin fan connector
(4) SATA 2.0 connectors
(1) ATX main power (2*10)
(1) ATX main power (2*2)
(2) 2x5 pin USB header
(1) RS232 header
(1) AUX-in header
(1) Power button header
(1) front audio connector
(1) PCIE x 16
(1) PCIE x 1 |
| FRONT PANEL |
(2) USB 3.0 Port
(1) USB 2.0 + E-SATA Port
(1) External microphone jack 1/8
(1) External headphone jack 1/8
Power button
HDD/ODD Led |
| BACK PANEL |
(4) USB 2.0 Ports
(2) USB 3.0 Ports
(1) E-SATA Port
(1) RJ45
(1) Audio Front out jack 1/8
(1) Audio Rear surround jack 1/8
(1) Audio Side surround jack 1/8
(1) Audio Center/Bass jack 1/8
(1) Line in jack 1/8
(1) S/PDIF Optical out
(1) CMOS clear button
(1) DVI Port
(1) HDMI Port |
| DIMENSIONS |
323(L) x 208(W) x 196(H) mm (w/ foot rubber) |
| POWER |
80 Plus 300W power supply
Input:100 - 240V AC
Support 80 PLUS Bronze
|
| ACCESSORIES |
XPC Multi-Language quick guide
XPC DVD Driver (include Adobe Reader 8.1)
I.C.E Technology CPU heat-pipe
Cables:
(2) SATA cable (pre-install)
(1) SP/DIF cable (pre-install)
(1) 1 set 4pin to SATA power cable
(1) Power cord
Others:
Screws
Heatsink Compound
Thermal grease |
| EXPANSION SLOT |
(1) PCI-E X16 slot
(1) PCI-E X1 slot (mechanically compatible with PCI-E x4 card)
(1) Mini-PCIE socket |
