The SH61R4 comes with two USB 3.0 ports situated on the back I/O. With greater demands for transferring larger files at faster speeds, USB 3.0 promises to be a welcome improvement from 2.0 technology. For external enclosures using USB 3.0, it would reduce backup times considerably, improving productivity and efficiency.
Dual View technology offers multiple display support on up to two separate monitors. This improves the capabilities and productivity of the user by allowing them to spread multiple windows over two monitors and viewing them simultaneously. The SH61R4 also supports full HD 1080p Blu-ray technology that makes it a budget PC while enjoy the benefits of multifunction.
Customizable Front Panel
The SH61R4 includes a customizable front, with endless design and dcor possibilities for home and business users. You can decide the design of the panel to your own wishes. The SH61R4 comes with a removable acrylic cover to make this possible. Any design that you want can be placed behind it. Whether a company logo, administrative data or your favorite photo let your creativity begins, the options are virtually unlimited.
Quick boot solution
The Shuttle XPC Barebone SH61R4 comes with a Mini PCI-e slot which provides an easy way for users to add an internal device such as SSD storage module and wireless card in addition to USB and PCI-e interfaces. Users can secure fast boot-ups and application load times and thus enjoy a faster and smarter performance.
Specifications
| FORM FACTOR |
Shuttle Form factor |
| PROCESSOR |
Intel next grneration Core i7, Core i5 and Core i3 processor LGA1155 socket
95w max. Support |
| CHIPSET |
Intel H61 |
| MEMORY |
DDR3 1333 MHz support RAM Socket * 2, Dual channels support
up to 8 GB total (4GB*2) |
| VGA |
Integrated in CPU |
| AUDIO |
IDT92HD89C
5.1 channel High Definition Audio |
| ETHERNET |
Realtek RTL 8111E
10Mb/s,100Mb/s,1Gb/s operation
Support Wake-ON-LAN function |
| STORAGE INTERFACE |
SATA 3G |
| ONBOARD CONNECTORS |
(1) 4 Pin fan connector
(1) 3 Pin fan connector
(4) SATA 2.0 connectors
(1) ATX main power (2*10)
(1) ATX main power (2*2)
(1) 2x5 pin USB header
(1) RS232 header
(1) AUX-in header |
| FRONT PANEL |
(2) USB 2.0 Port
(1) External microphone jack 1/8
(1) External headphone jack 1/8
Power button
HDD/ODD Led |
| BACK PANEL |
(6) USB 2.0 Ports
(2) USB 3.0 Ports
(1) Line in jack 1/8
(1) Line out jack 1/8
(1) CMOS clear button
(1) DVI Port
(1) DVI-D Port |
| DIMENSIONS |
325(L) x 215(W) x 190(H) mm (w/o foot rubber) |
| POWER |
250W power supply
Input:100 - 240V AC |
| ACCESSORIES |
XPC Multi-Language quick guide
XPC DVD Driver (include Adobe Reader 8.1)
Heat-sink compound
Power cord |
| EXPANSION SLOT |
(1) PCI-E X16 slot
(1) PCI-E X1 slot (mechanically compatible with PCI-E x4 card)
(1) Mini-PCIE socket |
