| Display |
H-Scanning Frequency |
30 ~ 81 kHZ |
| Maximum Pixel Frequency |
148,5 MHz |
| V-Scanning Frequency |
56 ~ 75 HZ |
| Panel |
Diagonal Size |
46" |
| Type |
60 Hz LED BLU S-PVA |
| Resolution |
1.920 x 1.080 (16 : 9) |
| Pixel Pitch(mm) |
0,36375 (H) x 0,36375 (V) |
| Active Display Area |
1036,08 (H) x 591,30 (V) |
| Brightness |
300 nit |
| Viewing Angle (Horizontal/Vertical) |
300 nit |
| Response Time (G-to-G) |
8 ms |
| Display Color |
10 bit Dithering - 1,07 Billion |
| Color Gamut |
73% |
| Contrast Ratio |
5.000 : 1 |
| Connectivity |
Input |
RGB |
Analog D-SUB |
| Video |
Component (CVBS Common), HDMI |
| Audio |
Audio-in |
| Output |
Audio |
Digital Audio out (Optical), Head phone out |
| Mechanical Spec |
Dimension |
Set Dimension (WxHxD) |
41,59" x 24,11" x 1,18" |
| Package Dimension (WxHxD) |
46,06" x 28,74" x 7,83" |
| Weight |
Set Weight |
12,5 kg |
| Package Weight |
16,6 kg |
| VESA Mount |
400 x 400 mm |
| Stand Type |
Foot Stand (optional) |
| Operation |
Operating Temperature |
10C ~ 40C |
| Humidity |
10 ~ 80% |
| General Feature |
Key |
LED BLU LFD with built-in simple media player & TV tuner |
| Special |
Built in TV, Built in Speaker (10 W + 10 W), Plug and Play (thru USB), Simple media player, Narrow bezel, Slim depth (29,9, mm) |
| Power |
Power Supply |
AC 100 - 240 V~ (+/- 10 %), 50 / 60 Hz |
| Power Consumption |
Off Mode |
Less than 1 W |
| On Mode |
160 (Max) / 140 (Typ) |
| Type |
Internal |
| Accessory |
Included |
Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries |
| Optional |
Mount |
WMN4270SD WMN2000BD |
| Specialty |
CML450D (ceiling mount) |
| Stand |
STN-LE4055AD |
| Certification |
EMC |
FCC (USA) FCC Part 15, Subpart B class BCE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22) KCC (Korea): KN22, KN24BSMI (Taiwan): CNS13438 (CISPR22) C-Tick (Australia): AS/NZS3548 (CISPR22) CCC(China): GB 9254-2008, GB 17625.1-2003 |
| Environment |
ENERGY STAR 5.0 (USA) |
| Safety |
CUL (USA+Canada): UL60065 TUV (Germany): EN60065CB (Europe): IEC60065 / EN60065EK (Korea): K60065 CCC (China): GB8898PSB (Singapore ): IEC60065 GOST (Russia ): IEC60065, EN55022 SIQ (Slovenia ): IEC60065, EN55022 PCBC (Poland ): IEC60065, EN55022 NOM (Mexico ): NOM-001-SCFI-1993IRAM (Argentina ): IRAMSASO (Saudi Arabia ) : IEC60065 |
