- UEFI BIOS(EZ Mode) - Flexible & Easy BIOS Interface
- Integrated AMD Dual-Core Processor E-450 with AMD Radeon HD 6320 Graphics
- Protect3.0 - Protect the Earth & the system & you
- AI Suite II - One-stop Access to Innovative ASUS Features
Overview
Integrated AMD Dual-Core Processor E-450 with AMD Radeon HD6320 Graphics
This motherboard supports integrated AMD Dual-Core Processor E-450 with AMD Radeon HD 6320 Graphics. This revolutionary APU (Accelerated Processing Unit) combines processing power and advanced DirectX 11 graphics in one small, energy-efficient design to enable accelerated performance and an industry-leading visual experience. It features single-channel DDR3 memory support and accelerates data transfer rate up to 2.5GT/s
AMD FCH A50M (Hudson M1)
AMD FCH A50M (Hudson M1) is designed to support up to 2.5GT/s interface speed and PCI Express 2.0 x 16 (at x4 speed) graphics. It supports 6 x SATA6Gb/s ports and 14 x USB 2.0 Ports.
HDMI Support
Enjoy Full HD 1080p Multimedia Home-Theater Entertainment
High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals through a single cable. Supporting HDCP copy protection such as HD DVD and Blu-ray Discs, HDMI provides you with the highest-quality home theater experience.
100% All High-quality Conductive Polymer Capacitors!
This motherboard uses all high-quality conductive polymer capacitors onboard for durability, improved lifespan, and enhanced thermal capacity
ASUS EPU
The ASUS EPU (Energy Processing Unit) provides total system power management by detecting current PC loadings and intelligently moderating power in real-time. It automatically provides the most appropriate power usage to save power and money!
Anti-Surge Protection
This special design prevents expensive devices and the motherboard from damage caused by power surges from switching power supply (PSU).
TurboV
Accessible Performance on Demand
This intutive performance-improvement tool allows users to adjust the system performance paramaters with just a few clicks through its user-friendly interface. ASUS TurboV also allows users to save several profile settings to suit system performance scenarios as well.
Turbo Key II
Switch on the Potential, Turn up the Performance!
Enjoy superb performance by auto-tuning your processor to an extreme yet stable state. Simply activate a dedicated switch on the motherboard to unleash extra processing capabilities.
Fan Xpert
Active Quiet & Cool
ASUS Fan Xpert intelligently allows users to adjust both the CPU and chassis fan speed according to different ambient temperature , which is caused by different climate conditions in different geographic regions and system loading.Built-in variety of useful profiles offer flexible controls of fan speed to achieve a quiet and cool environment.
AI Suite II
One-stop Access to Innovative ASUS Features
With its user-friendly interface, ASUS AI Suite II consolidates all the exclusive ASUS features into one simple to use software package. It allows users to supervise overclocking, energy management, fan speed control, voltage and sensor readings, and even interact with mobile devices via Bluetooth. This all-in-one software offers diverse and ease to use functions, with no need to switch back and forth between different utilities.
USB 3.0 Support
Experience ultra-fast data transfers at 4.8Gbps with USB 3.0--the latest connectivity standard. Built to connect easily with next-generation components and peripherals, USB 3.0 transfers data 10X faster and is also backward compatible with USB 2.0 components.
Native Serial ATA 6Gb/s support
The AMD Hudson M1 Chipset natively supports the Serial ATA (SATA) interface, delivering up to 6.0 Gb/s data transfer. ASUS provides extra SATA 6.0 Gb/s ports with enhanced scalability, faster data retrieval, and double the bandwidth of current bus systems.
Stylish Heatsink
The stylish heatsink features a 0-dB thermal solution that offers users a noiseless PC environment. Not only the beautiful shape upgrades the visual enjoyment for motherboard users, but also the heatsink design lowers the temperature of the chipset and power phase area through high efficient heat-exchange. Combined with usability and aesthetics, the ASUS stylish heatsink will give users an extremely silent and cooling experience with the elegant appearance!
GreenASUS
The motherboard and its packaging comply with the European Union's Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers' health while minimizing the impact on the environment.
Specifications
| CPU |
AMD Fusion APU E-450 Dual-Core onboard Processors
Supports AMD Turbo Core Technology |
| Chipset |
AMD FCH A50M (Hudson M1) |
| Memory |
2 x DIMM, Max. 8GB, DDR3 1600(O.C.)/1333/1066 MHz Non-ECC, Un-buffered Memory
Single Channel Memory Architecture
* Refer to www.asus.com or user manual for the Memory QVL (Qualified Vendors Lists).
* Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows OS when you want to install 4GB or more memory on the motherboard. |
| System Bus |
Up to 2.5 GT/s UMI Link |
| Graphic |
Integrated ATI Radeon HD 6320 GPU
Multi-VGA output support : HDMI/DVI/RGB ports
- Supports HDMI with max. resolution 1920 x 1080 @ 60 Hz
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 2560 x 1600 @ 60 Hz
Supports DirectX 11 |
| Expansion Slots |
1 x PCIe 2.0 x16 (x4 mode)
1 x PCIe 2.0 x1
2 x PCI |
| Storage |
Built-in Controller :
5 x SATA 6Gb/s port(s), white
1 x eSATA 6Gb/s port(s), red |
| LAN |
Realtek 8111E , 1 x Gigabit LAN Controller(s) |
| Audio |
Realtek ALC887 8-Channel High Definition Audio CODEC *1
- Supports : Multi-streaming, Front Panel Jack-retasking, Anti-pop Function
Audio Feature :
- Optical S/PDIF out port(s) at back panel |
| USB Ports |
ASMedia USB 3.0 controller :
2 x USB 3.0 port(s) (2 at back panel, blue)
Built-in Controller :
12 x USB 2.0 port(s) (4 at back panel, black+red, 8 at mid-board) |
| Special Features |
ASUS EPU :
- EPU
ASUS Protect 3 Technology :
- Anti-Surge Protection
- Low EMI Solution
Turbo Key
Turbo Key II
TurboV
ASUS Exclusive Features :
- AI Suite II
- Ai Charger+
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
ASUS Quiet Thermal Solution :
- ASUS Fan Xpert
ASUS EZ DIY :
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2 |
| Back I/O Ports |
1 x PS/2 keyboard/mouse combo port(s)
1 x DVI
1 x D-Sub
1 x HDMI
1 x eSATA 6Gb/s
1 x IEEE 1394a
1 x LAN (RJ45) port(s)
2 x USB 3.0
4 x USB 2.0
1 x Optical S/PDIF out
3 x Audio jack(s) |
| Internal I/O Ports |
4 x USB 2.0 connector(s) support(s) additional 8 USB 2.0 port(s)
1 x COM port(s) connector(s)
5 x SATA 6Gb/s connector(s)
1 x IEEE 1394a connector(s)
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x parallel port connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
1 x Turbo Key II switch(es) |
| Accessories |
User's manual
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x CPU FAN |
| BIOS |
32 Mb Flash ROM, UEFI BIOS, PnP, DMI 2.0, WfM 2.0, ACPI 2.0a, SM BIOS 2.6 |
| Support Disc |
Drivers
ASUS PC Probe II
ASUS Update
Anti-virus software (OEM version) |
| Form Factor |
uATX Form Factor
9.6 inch x 7.2 inch ( 24.4 cm x 18.3 cm ) |
| Note |
*1: Choose the chassis with HD audio module in front panel to support 8-Channel audio output. |
