All stock codes associated to this product
TLMA180, TL-MA180
3.75G HSUPA USB Adapter
MA180
Highlights:
- Up to 7.2Mbps download and 5.76Mbps upload (Network Type: WCDMA)
- Micro SD card slot for up to 32GB of optional storage
- Bundled utility provides quick & hassle-free installation
- Internal antenna, no batteries or cables required
- Fast USB 2.0 connection to notebook/desktop computers
Overview
What This Product Does
TP-LINKs 3.75G HSUPA USB Adapter, MA180 allows users to acquire 3G mobile broadband access simply by inserting a standardSIM card into the adapter and plugging it into their laptop or desktop computers. It supports the latest 3.75G HSUPA technology, which provides improved data transfer rates. Equipped with its internal antenna, micro SD card slot and SIM card slot, the MA180 is a great choice for users to connect to the Internet in locations that are unable to receive conventional broadband. You can enjoy quick and easy access to email, the Internet or business applications on your laptop while on the go.
High Speed Data Transfer - Up to 7.2Mbps download and 5.76Mbps upload
With Up to 7.2Mbps download and 5.76Mbps upload speeds, the MA180 gives users a fluid Internet surfing experience. The devices high upload speed allows users to quickly send large files, such as e-mail with attachments, photos or business documents.
Micro SD Card Slot - Up to 32GB of Optional Storage
MA180 is equipped with a micro SD card slot thats compatible with SD Cards with capacity up to 32GB allowing users to use MA180 as a 3G USB modem and a USB memory stick at the same time.
Bundled Utility - Quick & Hassle-Free Installation
Using the MA180s bundled utility, users can get connected and enjoy the Internet in as little as two steps.
1.Insert the MA180 3G USB Adapter
2.Run Utility And youre connected!
Features:
- Up to 7.2Mbps download and 5.76Mbps upload (Network Type: WCDMA)
- Micro SD card slot for up to 32GB of optional storage
- Bundled utility provides quick & hassle-free installation
- Internal antenna, no batteries or cables required
- Fast USB 2.0 connection to notebook/desktop computers
- Take your Broadband connection with you wherever you go
- Supports Windows XP 32/64bit, Vista 32/64bit, Windows 7 32/64bit
- Provides HSUPA/HSDPA/UMTS/GPRS/GSM/EDGE network support
Specifications:
| HARDWARE FEATURES |
| Standards and Protocols |
WCDMA Network |
| Interface |
USB 2.0 |
| Data Rates |
DL: 7.2 Mbps, UL: 5.76 Mbps |
| LED Indicator |
Two-color LED provides status information |
| Dimensions ( W x D x H ) |
3.89 x 1.09 x 0.55 in. (99 x 28 x 14 mm) |
| Antenna Type |
Internal antenna |
| GSM Band |
850/900/1800/1900 MHz |
| HSUPA Band |
2100 MHz |
| Micro SD Card Reader |
Supports standard Micro SD cards up to 32 GB |
| SIM Slot |
Standard 6-Pin SIM card interface |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
MA180 3.75G HSUPA USB ADAPTER
Quick Installation Guide |
| System Requirements |
Windows 7 (32/64bits), Windows Vista (32/64bits), Windows XP (32/64bits) |
| Environment |
Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
