All stock codes associated to this product
0761345108591, 0-761345-10859-1, HCP1000PLATINUM, HCP-1000-PLATINUM
HCP-1000 PLATINUM
HCP PLATINUM SERIES
Antec’s High Current Pro Platinum series is the pinnacle of power supplies. High Current Pro Platinum is fully modular with a revolutionary 20+8-pin MBU socket for the needs of tomorrow. By using a PSU that is 80 PLUS® PLATINUM & ErP Lot 6: 2013 certified, operating up to 94% efficient, you can reduce your electricity bill by up to 25% when compared to many other power supplies. HCP Platinum’s innovative 16-pin sockets create a new level of flexibility by doubling the modular connectivity, supporting two different 8-pins connectors
and even future connectors of 10, 12, 14 or 16-pins. Backed by a 7 year warranty and lifetime global 24/7 support, the HCP-1000 Platinum embodies everything a power supply can accomplish today.
1000 W A T T, ATX12V V2.32, EPS12V V2.92, Full cable Management, Continuous Power, Max Efficiency, Max energy Savings
SPECIFICATIONS:
1000W Continuous Power - Guaranteed 1000W of Continuous Power from Antec
80 PLUS® PLATINUM certified - Up to 94% efficient, to reduce your electricity bill
Save Energy and Money - Reduce your electricity bill by up to 25%
AQ7 - Antec Quality 7 year warranty and lifetime global 24/7 support
16-pin Socket - Industry-leading 16-pin sockets double the modular connectivity by supporting 2 different 8-pin cables per socket and allow for future connector changes
28(20+8)-pin MBU socket - World's first socket for possibe future MBU connectors
135 mm DBB Silence - Whisper-quiet high-quality double ball bearing fan with long lifetime
Thermal Manager - An advanced low voltage fan control for optimal heat & noise management
High Current Rails - 4 High Current +12V rails with high load capabilities ensure maximum CPU & GPU compatibility
100% +12V - Output for maximum CPU & GPU support
Multi PCI-E - 6 PCI-E connectors for multiple GPU support
CircuitShield™ - Full suite of industrial grade protections: Over Current Protection (OCP), Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection
(SCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Surge & Inrush Protecion (SIP), No Load Operation (NLO) & Brown-Out Protection (BOP)
All Japanese Heavy-Duty Caps - All high-performance Japanese capacitors ensure tightest DC stability and regulation
ErP Lot 6: 2013 - Compliant to the toughest energy standard available
PhaseWave™ Design - A server-class full-bridge LLC design with a synchronous rectification based on a DC-DC topology
Stealth Wires - All wires darkened for minimal visibility in chassis
INPUT:
100VAC - 240VAC ~ ±10% (Active PFC) 50Hz - 60Hz, 13A - 6.5A
1 x 24-Pin
1 x 8 (4 + 4) pin (ATX 12V/EPS12V)
1 x 8 EPS12V
6 x 8(6 + 2)-pin PCI-E
6 x Molex
9 x SATA
1 x Floppy
