Seagate 2000GB (2TB) 7200rpm SATA-III 6Gbps HDD w. 64MB Cache (ST32000645NS) ES.2 Series

IMG 1 of 1
No Longer Available
Part Number:
191263
(?) Brand:
Seagate Web Site
Manuf No:
ST32000645NS
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
ST32000645NS, 763649028230, 7636490026782

Constellation ES Hard Drive


Model Number: ST32000645NS

Overview

Maximum capacity. Minimum effort.

Seagate Constellation ES hard drives can reduce data storage costs by combining high capacity and power efficiency with industry-leading reliability.

  • Capacity Maximize your data center footprint by storing up to 114TB per square foot
  • Efficiency Save on power and cooling costs with PowerChoice technology
  • Enterprise-class reliability Ensures consistent, scalable and reliable data access 24x7
  • Highest data integrity Enterprise-class 6Gb/s SAS ensures data is stored reliably
  • Protect your data with SED and/or FIPS 140-2 compliant options1

3.5 Constellation ES overview 1


Trims per gigabyte storage costs.

Maximize your data center footprint with Constellation ES.2 drives. These capacity-optimized 2 and 3 TB enterprise hard drives support up to 114 TB of storage per square foot, and they offer industry-leading low power consumption.

Additionally, each Constellation ES generation includes Seagate PowerChoice™ technology for even greater savings. This innovative technology empowers IT organizations to manage storage solutions for optimal power consumption.

SED optimizes security and ROI.

Constellation ES hard drives feature Self-Encrypting Drive models that improve data-at-rest security and enhance return on investment.

SED models with Seagate Instant Secure Erase technology cut IT drive retirement costs while securely protecting data where it lives - on the drive.

3.5 Constellation ES overview 2

3.5 Constellation ES overview 3

Reliable data access 24x7.

Each generation of Constellation ES drives features industry-leading innovations that deliver consistent, scalable and reliable data access along with robust nearline performance for multi-drive enterprise solutions.

Features:

3.5 Constellation ES Features 1

Save with Seagate PowerChoice technology.

Among 3TB enterprise drives, Constellation ES.2 features the lowest operating power in the industryless than 11.3W on average.

Additionally, Constellation ES drives enable further power reductions with enhanced PowerChoice technology. Purpose-built for enterprise environments, the PowerChoice feature enables the T10-compliant power management standard, allowing organizations to tailor systems for optimal energy usage.

The result: up to 90% more power savings.

3.5 Constellation ES Features 2

SED models optimize security and ROI.

Constellation ES hard drives feature Self-Encrypting Drive models that can improve data-at-rest security and enhance return on investment.

Seagate enterprise Self-Encrypting Drives are TCG-compliant and eliminate the need to overwrite or physically destroy the hard drive for security purposes. This enables organizations to swiftly protect sensitive data and securely return, repurpose or sell the drive, thereby reducing drive retirement costs.

For stringent regulatory compliance needs, Constellation ES drives are also available as a FIPS (140-2) Validated SED. These SED models are NIST-certified to secure Sensitive but Unclassified and Protected class data.

Self-Encrypting Drives (SED) and FIPS 140-2 Validated drives are not available in all models or countries.
May require TCG-compliant host or controller support.
TM: The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.


Drive reliability you can trust.

Constellation ES drives offer a range of capacities along with two interface options, including a traditional SATA 6Gb/s and the latest 6Gb/s SAS.

Every generation of Constellation ES drives features the highest level of of multi-drive reliability for a 24x7 capacity-optimized drive experience.

  • 1.2M MTBF and 0.73% AFR
  • Data is stored accurately with SAS-based advanced error detection and correction
  • Best-in class rotational and linear vibration tolerance ensures consistent, reliable data access and performance in multi-drive systems
  • Multi-drive firmware maximized for enterprise system availability.

Specifications:

Generation ES.2 ES
Capacity 3TB 2TB 2TB 1TB 500GB


Form Factor 3.5" 3.5" 3.5" 3.5" 3.5"
Interface Options SATA 6Gb/s, SAS 6Gb/s SATA 6Gb/s, SAS 6Gb/s SAS 6Gb/s, SATA 6Gb/s, SATA 3Gb/s SAS 6Gb/s, SATA 6Gb/s SAS 6Gb/s, SATA 6Gb/s, SATA 3Gb/s
Performance
Spindle Speed (RPM) 7200 7200 7200 7200 7200
Cache (MB) 64 64 16, 64 64, 16 64, 32, 16
Transfer Rate, Max Ext (MB/s) 600 600 600, 300 600 600, 300
Sustained Data Rate OD 155MB/s 155MB/s 150MB/s, 147Mb/s, 140MB/s 147Mb/s, 150MB/s 147Mb/s, 140MB/s, 150MB/s
Average Latency (ms) 4.16 4.16 4.16 4.16 4.16
Reliability/Data Integrity
Nonrecoverable Read Errors per Bits Read 1in 1015 1in 1015 1in 1015 1in 1015 1in 1015
Annualized Failure Rate (AFR) 0.73% 0.73% 0.73%% 0.73%% 0.73%%
Power Management
Seek, Typical Operating (W)         6.76
Idle, Typical Operating (W) 7.71, 7.40 7.71, 7.40 7.26, 5.69, 6.24, 6.39 5.16, 4.42, 5.41 4.32, 4.56, 3.74, 4.67
Environmental
Temperature
Operating 5to60C 5to60C 5to60C 5to60C 5to60C
Non-operating -40to70C -40to70C -40to70C -40to70C -40to70C
Shock
Operating: Gs (ms) 70 / 40(2ms), 70/40(2ms) 70/40(2ms), 70 / 40(2ms) 70/40(2ms), 70(2ms), 70/40(2300ms), 70 /40(2ms) 70(2ms), 70/40(2ms) 70(2ms), 70/40(2ms)
Non-operating: Gs (ms) 300(2ms) 300(2ms) 300(2ms), 2(ms) 300(2ms), 350(2ms) 300(2ms), 350(2ms)
Acoustics (bels - sound power)
Idle 2.8 2.8 2.7 2.7, 1.9 2.7, 2.2, 1.9
Operating 3.2 3.2 3.0 2.7 2.8, 2.7
Physical
Height (in/mm)     1.028/26.10 1.028/26.10 1.028/26.10
Width (in/mm)     4.010/101.85 4.010/101.85 4.010/101.85
Length (in/mm)     5.787/147.00 5.787/147.00 5.787/147.00
Height (in/mm) (maximum) 1.028/26.10 1.028/26.10
Width (in/mm) (maximum) 4.010/101.85 4.010/101.85
Length (in/mm) (maximum) 5.787/147.00 5.787/147.00
Weight (lb/g) 1.543/700 1.543/700 1.57/710, 1.565/710 1.41/640, 1.345/610 1.34/610, 1.411/640, 1.345/610

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Seagate) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
