Onboard PC audio gets better! MSI is the first to implement the most high-end HD Audio codecs available. Dont be fooled by other inferior audio solutions onboard (sometimes you cant even find the driver!) Only MSI offers the Loss-less 24-bit/192KHz HD Audio function with an incredible 109 SNR dB value to provide the most clear & vivid HD audio quality and support 7.1 channels surround sound playback with a 2-channel independent stereo output (multiple streaming) through the front panel 3.5 inch phone jack.









Winki3 is a free Linux-based O/S which is based on the Linux core. With an ultra-fast booting speed and a multi-language interface, the built-in Winki3 provides an easy-to-use internet environment that includes the most popular functions such as internet surfing, web mail, instant messaging, picture browsing, and more. It's the most practical way to be online in the shortest time.


User friendly & totally free applications
Power on to run applications in 25 seconds
Multi-language interface support







OC Genie II, the most powerful and easy overclocking technology is implemented on MSI's AMD 9-Series mainboards. MSI's OC Genie II completely automates advanced overclocking functions and offers up to 248% higher performance with the simple click of a button. It does not matter if you're a first time hardware owner, or a veteran overclocker, activating MSI OC Genie II will unlock your hidden CPU cores, overclock your CPU and your memory to simply give you the best and stable performance for free on MSI AMD 9-Series mainboard available.



Automatically overclock & unlock hidden CPU core(s) in 1 second
Instantly boost system performance up to 248%







The perfect trinity of quality, stability and efficiency all exist at one mainboard to meet end user expectations. The MSI Military Class II series products provide the long lifespan, unparalleled quality, extreme performance and ultimate efficiency.

Insisting on the best stability, MSI utilizes Hi-c CAPs on Military Class series.  Made of the rare element Tantalum, often used on space shuttles and satellites, which sustains very high temperatures and shows an amazingly high electrical conductivity.



SFC(Super Ferrite Choke).The super Ferrite Chokes use a Ferrite core that is Super-Permeable. Compare with traditional choke, the Super Ferrite Chokes run at a 35 degree Celsius lower temperature. The lower working temperature will enhance mainboard stability.



For providing the highest quality products, we built-in Solid CAP in the entire Military Class series. This not only makes bursting capacitors a non-issue but also ensures a dramatically extended lifetime and ultra-low ESR.







THX is a trade mark of a high-end audio/visual reproduction standard for movies, home theaters, computer speakers and other audio devices. THX Certified Audio products are designed to let users experience movies & videos as live show. The true sound effect can make high definition video more powerful.



A high-fidelity sound reproduction standard
Accurately reproduce the fullest audio experience of movie, music and game soundtracks







Mobile consumer appliances are getting more and more attention in current day fast moving life style, with smart phones and tablets almost becoming a fashion accessory. However, many ordinary personal computers cannot charge some of these devices, making it difficult to stay connected.  The MSI Super Charger is a Windows resident program capable of revising the power supply mode of your USB port to become more powerful. Once your phone or tablet is connected to your USB port, the Super Charger sends a signal to initiate its charging circuit, making it a really smart and convenient charging solution for mobile computing needs.



Instant MB info monitor
Green Power: CPU Phase, system fan speed controlled with max power saving
Smart Mode: 4 instant OC modes







Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gb/s offers 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute. MSI also has implemented a front panel USB 3.0 port, making the use of an external USB 3.0 device even more convenient.





10X Faster Than USB 2.0
Up to 5Gb/s Data Transfer Bandwidth
World’s first to provide Front Panel USB 3.0 Port
Boost Transfer Rate Between Your PC and External Storage Devices







SATA 6Gb/s provides double the bandwidth of traditional SATA 3Gb/s, and increases the data transfer rate between your mainboard and internal storage devices, such as 7200RPM HDDs, 10000RPM HDDs and SSDs. It’s also the current trend for upcoming high-speed internal storage devices to to break the existing bottleneck of a PC’s performance.



2X Faster Than SATA 3Gb/s
Up to 6Gb/s Data Transfer Bandwidth
Unleash True Performance of New HDDs/SSD's







Active Phase Switching, APS, technology is an intelligent design that helps to save energy on MSI’s mainboards. The underlying idea is to switch off the power supply as soon as no electricity is needed, and when the system needs more resources again, APS will automatically adjust electricity supply accordingly. APS will automatically detect your processor’s loading at any given time and save energy accordingly. This is only possible by means of a very advanced power controlling technology. Other than software-based solutions, APS technology stands out from MSI's own research. The specially developed IC chip can operate automatically depending on the demands of the power supply, which is to reduce the total power usage.









Compared to common mainboard which need extra BIOS chips, MSI’s M-Flash has a double advantage which doesn’t need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover it can also be seen as a portable BIOS chip which is actually able to boot up your PC.





Backup/Restore Your BIOS to/from Any USB Flash Disk
Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process
Earn more BIOS Lifespan by Reducing Unnecessary Rewriting Process





USB Safeguard can prevent mainboards and USB devices from being damaged by short-circuit and ESD (Electro-Static Discharge) with Anti-ESD chips built-into the mainboards. Additionally, the safeguard can protect against such dangers multiple times, and greatly improves product lifespan.



All MSI mainboards use USB Safeguard’s anti-ESD chip for thorough protection against ESD damage
USB Safeguard is protected against a short circuit and/or ESD without the need for a fuse. It also supports stand-by power supply







AMD CrossFireX™ is the ultimate multi-GPU performance gaming platform. Enabling game-dominatig power, AMD CrossFireX technology enables two or more discrete graphics processors to work together to improve graphics performance. AMD CrossFireX technology allows you to expand your system’s graphics capabilities. It allows you the ability to scale your system’s graphics horsepower as you need it, supporting up to four AMD Radeon™ HD graphics cards, making it the most scalable gaming platform ever. With an AMD CrossFireX gaming technology, the traditional graphics limitation exists no more, allowing you to enjoy higher performance as well as visual experience.







MSI Live Update 5 is a powerful and useful application for updating the latest BIOS and Drivers, saving you time and lowers the risk of updating. End-users can install and run the Live Update 5 software on their computers with the companion CD or downloading the app from the MSI website.



Automatically Detect the BIOS/Driver/VGA/Utility Update
Support Microsoft Windows 98SE/ME/2000/XP/Vista/7 32Bit







SLI technology allows using multiple Nvidia graphics cards in a single computer system with a mainboard equipped with an nForce SLI MCP. Users need an a mainboard with two PCI-Express 16x graphics slots and two matching GeForce graphics cards which are "SLI Ready". Most NVIDIA's PCI-Express graphics cards starting from the 6600 GPU can enjoy the benefits of SLI.







In order to provide customers stable and high quality products, starting from P45 series mainboards, MSI is leading the industry to introduce the world's most advanced power supply component, DrMOS (Driver-MOSFET), which integrates Driver IC, Top MOSFET and Bottom MOSFET into one chip. Except for its outstanding performance in power saving, DrMOS possesses switch frequency which is 400% faster than traditional MOSFET and has great improvement in stabilizing power supply and voltage control. Even under heavy loading and overclocking conditions, DrMOS can still provide the most stable and efficient power supply and quality.







AMD Cool'n'Quiet™ Technology reduces heat and noise so you can experience amazing performance without distraction. Combined with core enhancements, included in the AMD processors, that can improve overall power savings, deliver better multitasking and energy efficiency. Cool'n'Quiet technology can automatically adjust processor ratio to throttle CPU speed with four modes.



Independent Dynamic Core Technology
Dual Dynamic Power Management™
AMD CoolCore™ Technology
AMD Wideband Frequency Control
Multi-Point Thermal Control







3TB+ Infinity is not only breaking through the limit of traditional BIOS, but also enhancing the utilization of hard drives efficiently. In addition to supporting the latest 3TB hard drives, MSI 3TB+ Infinity technology can use the 3TB hard drive as boot disk when installing a 64-bit operating system. Compared to competitors, MSI 3TB+ Infinity is an industry-leading technology which substantially presents an advantage of development and application in the future.



All the latest 3TB hard drivers on the market can be supported
Make the 3TB hard drive as boot disk when installing a 64-bit operating system





CPU (Max Support)	Phenom II
AM3 CPU Ready	Y
FSB / Hyper Transport Bus	up to 5200MT/s
Chipset	AMD 990FX+SB950
DDR2 Memory	N/A
DDR3 Memory	DDR3 800/1066/1333/1600/1800*/2133*(OC)
Memory Channel	Dual
DIMM Slots	4
Max Memory (GB)	32
PCI-Ex16	4
PCI-E Gen	Gen2 (2x16, 1x8, 1x4)
PCI-Ex4	N/A
PCI-Ex1	2
PCI	1
IDE	N/A
SATAIII	6
SATAII	N/A
RAID	0/1/5/10
LAN	10/100/1000*1
TPM	1
USB 3.0 ports (Rear)	2
USB 2.0 ports (Rear)	6
Audio ports (Rear)	6+Coaxial SPDIF/Optical SPDIF
Serial ports (Rear)	N/A
Parallel ports (Rear)	N/A
1394 ports (Rear)	1
eSATA	2
Display Port	N/A
DrMOS II	N/A
VGA	N/A
HDMI	N/A
DVI	N/A
VGA Max Share Memory (MB)	N/A
4-way SLI	N/A
DirectX	N/A
Form Factor	ATX
DrMOS	Y
APS	Y
Sideport Memory	N/A
Dual Graphics	N/A
SLI	Y
3-way SLI	Y
Hybrid SLI	N/A
CrossFire	Y
Hybrid CrossFire	N/A
D-LED2	N/A
Green Power Genie	N/A
