System |
CPU: Dual-core Intel AtomTM RAM: 2GB DDRIII Embedded OS: Windows 7 |
Backup |
Manual/Scheduled backup |
Camera Compatibility |
Full Integration with VIVOTEK Network Cameras |
EasySetup |
"Setup Wizard" for Network/HDD/Camera easy setup |
Export |
Format: AVI/3GPP/EXE |
Language Support |
English, French, German, Italian, Spanish, Traditional Chinese, Simplified Chinese, Japanese, Portuguese, Czech |
Local LiveView Monitor |
Display Layout: 1X1/2X2/3X3/4X4/5X5/1+5/1+12/1+31 E-Map Snapshot PiP Display Performance: MPEG-4: 2 streams 30 fps @ 1080p; 12 streams 30 fps @ CIF H.264: 1 stream 30 fps @ 1080p; 7 streams 30 fps @ CIF Auto Patrol (Display Layout) Pan/Tilt/Zoom control of VIVOTEK cameras Instant event notification Instant Replay: 20 sec., 30 sec., 1 min., 5 min., 15 min. Full HD local display by VGA connector
|
Local Playback |
Display Layout: 1X1/2X2/3X3/4X4/1+5/1+12 Playback Mode: Play, Pause, Stop, Next/Frame, Next/Previous Time Interval, Speed Control Search Mode: Browsing/Time/Event Bookmark |
Mobile APP Support |
VIVOTEK iViewer (iOS/Android) |
Recording |
Throughput: Max. 96 Mbps Recording Policy: Scheduled recording (event/continuous modes), manual recording Video Compression: SVC/H.264/MJPEG/MPEG-4 Resolution: Up to 5-Megapixel recording Format: 3GPP Auto Recycling: Buffer size setting, time setting Activity Adaptive Recording
|
Storage |
2 x removable 3.5" SATA I/II HDD, up to 6TB 1 x external eSATA interface RAID 0, 1 |
channels |
8-CH |
Connectors |
2 x Gigabit, RJ45 4 x USB 2.0 1 x RS232 |
Alarm and Event Management |
Trigger Source: Motion, Temperature, Tampering, DI/O, IR, PIR, IVA, Video lost, Recording error, Recording status, Substation connection status, Storage connection status, Storage capacity status, License status, Network status & memory status Actions: Email, Start recording, Move to the preset position, Set DO, GSM short message & Send CGI command |
Security |
5 levels of user roles Multi-level user access with password protection |
Dimensions |
315mm(W)x220mm(D)x75mm(H) |
Weight |
Net: 2270 g (without HHD) |
LED Indicator |
1 x Power Status 1 x HDD Status |
Power |
Input: AC 100-240 V, 50-60 Hz Output: DC 12V 5A (60 W) Power Consumption: Max. 31 W |
Approvals |
CE, FCC Class B, VCCI, C-Tick |
Operating Environments |
Temperature: 0C ~ 40C Humidity: 20%~95% RH |
Warranty |
24 months |
