Please be aware that due to the large size of many products in this cateogry (Commercial Displays) additional freight may be required after completing your order. This covers various aspects of delivery - tailgates, if you do not have a forklift attract an additional charge. Or it can simply be that our freight system for extremely large products does not cope. Where possible we do absorb these additional fees but it varies order to order as well as upon yur delivery location.
All stock codes associated to this product
LH46CPPLBB/XY, UD46A, 1811664
46" UD46A LED Video Wall
UD46A
46" UD46A LED Video Wall
Features:
Choose the right view, landscape or portrait.
This Samsung LFD gives you the flexibility to display your image vertically or horizontallywhatever the situation calls for. With a pivot function that rotates the screen 90degrees and the freedom to display presentations in portrait mode or advertisements in landscape mode, this makes for one versatile monitor.
A video wall that lives up to your standards
Create the ultimate video wall with Samsung LFDs that cater to your needs. And because this LFD has an embedded video matrix processor, it supports 1 x 1 to 10 x 10 wall formats, allowing you to enjoy total convenience. Best yet, since they need no additional support, the possibilities are almost endless.
MagicInfo TM Software
Samsungs Digital Signage features two types of software: Wan/Lan-based for local access and web based software thats accessible anywhere. MagicInfo lets you access your server and LFDs everywhere in the world. This optimized Samsung software solution lets you manage multiple Samsung LFDs remotely. Best yet, creating, uploading and scheduling content, as well as monitoring and controlling LFDs is now more convenient and less time-consuming.
Specifications:
Display
| H-Scanning Frequency |
30 - 81kHz |
|
| Maximum Pixel Frequency |
148.5MHz |
|
| V-Scanning Frequency |
56 - 85Hz |
|
Panel
| Diagonal Size |
46" |
|
| Type |
S-PVA (DID) |
|
| Resolution |
1920 x 1080 |
|
| Pixel Pitch(mm) |
0.53025 (H) x 0.53025 (V) mm |
|
| Active Display Area |
1,018.08 x 572.67mm |
|
| Brightness |
700cd/m |
|
| Contrast Ratio (Dynamic) |
10000:1 |
|
| Viewing Angle (Horizontal/Vertical) |
178 / 178 |
|
| Response Time (G-to-G) |
8ms |
|
| Display Colour |
8 bit - 16.7M |
|
| Colour Gamut |
69% |
|
| Contrast Ratio |
3000:1 (TBD) |
|
Connectivity
| Input |
RGB |
Analog D-SUB / DVI-D / Display Port |
| |
Video |
CVBS / HDMI1 / HDMI2 / Component(D-sub 15pin) |
| |
Audio |
RCA (L / R) / Stereo mini Jack |
| Output |
RGB |
DVI-D (Loop-out) |
| |
Audio |
Stereo mini Jack |
| |
Power Out |
5V |
| External Control |
RS232C (in / out) / RJ45 |
|
| External Sensor |
Attached |
|
Mechanical Specification
| Dimension |
Set Dimension (WxHxD) |
1,023.8 x 96.0 x 578.4mm |
| |
Package Dimension (WxHxD) |
1,160 x 295 x 707mm |
| Weight |
Set Weight |
18kg |
| |
Package Weight |
25kg |
| VESA Mount |
600 x 400mm |
|
Operation
| Operating Temperature |
0 - 40C |
|
| Humidity |
10 - 80% |
|
General Feature
| Key |
Super Narrow Bezel |
|
| Special |
Lamp Error Detection / Anti Retention / Temperature Sensor / RS232C / RJ45 MDC,Plug and Play (DDC2B) / PIP / PBP / Video Wall (10 x 10) / Pivot Display / Button Lock / Digital Daisy Chain / Smart Scheduling / Smart F/W update |
|
Power
| Power Supply |
AC 100 - 240V~ (+/- 10 %) / 50 / 60Hz |
|
| Power Consumption |
Off Mode |
Less than 1W |
| |
On Mode |
MAX 220 |
| |
Sleep Mode |
Less than 1W |
| Type |
Internal |
|
Accessory
| Included |
Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries, Panel Cover |
|
| Optional |
Mount |
WMN-4655MD |
| |
Specialty |
MID-UD46FS |
Certification
| EMC |
FCC (USA) FCC Part 15, Subpart B class BCE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22) KCC (Korea):KN22, KN24BSMI (Taiwan) : CNS13438 (CISPR22)C-Tick (Australia) : AS / NZS3548 (CISPR22) CCC (China):GB 9254-2008, GB 17625.1-2003 |
|
| Environment |
ENERGY STAR 5.0 (USA) |
|
| Safety |
UL (USA) : UL 60950-1CSA (Canada) : CSA C22.2 No. 60950-1TUV (Germany) : EN60950-1NEMKO (Norway) : EN60950-1KC (Korea) : K60950-1CCC (China) : GB 4943-2001PSB (Singapore) : IEC60950-1GOST (Russia) : IEC60950-1, EN55022SIQ (Slovenia) : IEC60950-1, EN55022PCBC (Poland) : IEC60590-1, EN55022NOM (Mexico) : NOM-019-SCFI-1993IRAM (Argentina) :IEC60950-1SASO (Saudi Arabia) : IEC60950-1 |
