All stock codes associated to this product
R505CBXO003H, R505CB-XO003H
R505CB
Sleek and powerful Ultrabook with optical drive
- Windows 8 or other editions available
- Fits an optical drive in 21mm
- Enjoy SonicMaster Lite for more powerful sound performance
- Instant on in 2 seconds and longer standby time with the efficiency of Super Hybrid Engine II technology
- Smart Gesture touchpad for always fingertip-natural computing
- Combines SSD performance and HDD capacity for better computing experiences
Overview
Sleek aesthetic design
Beyond being extra thin and light, ASUS R505 ultrabooks pack a full feature set in just 21mm. The cool grey hairline design expresses a personal approach. One-piece molded top casing reinforces notebook strength and rigidity, and the entire style embodies subtlety that meets all your performance portability needs.
Amazing audio
ASUS SonicMaster Lite gives the ASUS R505 Series the ability to deliver more powerful sounds and richer bass to provide the best audio experience in the mainstream notebook class.
Smartphone-like responsiveness with instant on*
Only ASUS notebooks offer you true 2-second instant on resume from sleep or hibernate, cutting out long reboot times and putting you back to your enjoyment right where you left off. Thanks to ASUS Super Hybrid Engine II technology, you also get up to 13 days of standby, with auto data backup should battery charge drop to 5% or less.
Actual R505 standby time may vary due to specific component performance, connected devices, and environmental differentiation.
User-centric innovations
The large Smart Gesture touchpad enables always fingertip-natural computing, and the back-assembled chiclet keyboard assures extra-solid typing for greater comfort.
Reliable Performance
Windows 8 or other editions available, The ASUS R505CB features up to 3rd generation Intel Core i7 processors with Ivy Bridge technology and NVIDIA GT 635 series discrete graphics, so you're always in charge of smooth power for daily computing.
Specifications
| Processor |
Intel® Core™ i5-3317U Processor 1.70 GHz (3M Cache, up to 2.60 GHz Turbo)
|
| Operating System |
Windows 8 |
| Chipset |
Intel HM76 Express Chipset |
| Memory |
4GB DDR3 1600 MHz SDRAM, 2 x SO-DIMM socket for expansion up to 8 GB SDRAM |
| Display |
15.6" 16:9 HD (1366x768) LED Backlight |
| Graphic |
2GB DDR3 NVIDIA GT740M |
| Storage |
2.5" SATA
500GB 5400
24GB SSD Cache |
| Optical Drive |
DVD-S Writer |
| Card Reader |
Card Reader ( SD ) |
| Camera |
HD Web Camera |
| Networking |
Integrated 802.11 b/g/n
Built-in Bluetooth V4.0
10/100/1000 Base T |
| Interface |
1 x COMBO audio jack
1 x VGA port/Mini D-sub 15-pin for external monitor
1 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI |
| Audio |
Built-in Speakers And Microphone
|
| Battery |
4Cells 2950 mAh 44 Whrs |
| Power Adapter |
Output :
19 V DC, 3.42 A, 65 W
Input :
100 -240 V AC, 50/60 Hz universal |
| Dimensions |
38 x 26.6 x 2.10 ~2.10 cm (WxDxH) |
| Weight |
2.30 kg (with 4 cell battery) |
| Manufacturer Warranty |
1-year limited International hardware warranty. *different by country
On-line problem resolution through web interface (BIOS, Driver update)
OS (Windows 7 ) install/uninstall consultation
Bundled software install/uninstall consultation
ASUS software supporting |
