Image Sensor
| Sensor Type |
CCD |
|
| Effective Pixel |
Approx 16.2MP |
|
| Total Pixel |
Approx 16.56MP |
|
Lens
| Focal Length |
25mm (Equivalent to 25mm in 35mm format) |
|
| F No. |
F2.5-6.3 |
|
| Optical Zoom |
5X |
|
| digital zoom |
Still Image Mode: 1-5X, Play Mode: 1-14.4X (Depends on Image Size) |
|
Image Stabilisation
| mode |
DIS (Digital Image Stabilisation) |
|
Display
| type |
TFT LCD |
|
| Size |
3" |
|
| Features |
3" (75mm) 230,000 |
|
Focusing
| Range |
Normal: 80cm~Infinity (Wide), 250cm~Infinity (Tele), Macro: 5cm~80cm (Wide), 100cm~250cm (Tele), Auto Macro: 5cm~Infinity (Wide), 100cm~Infinity (Tele) |
|
Shutter Speed
Smart Auto: 1/8~1/2,000 seconds, Programme: 1~1/2,000 seconds, Night: 16~1/2,000 seconds, Fireworks: 2 seconds
Exposure
| Control |
Programme AE |
|
| Metering System |
Multi, Spot, Centre-weighted, Face Detection AE |
|
| Compensation |
2EV (1/3EV steps) |
|
| ISO Equivalent |
Auto, 80, 100, 200, 400, 800, 1,600, 3,200 |
|
Flash
| mode |
Auto, Auto & Red-eye reduction, Fill-in flash, Slow sync, Flash Off, Red-eye fix |
|
| Range |
Wide: 0.8m~4.0m, Tele: 0.5m~1.6m(iso) |
|
| Recharging Time |
5 seconds |
|
White Balance
| mode |
Auto WB, Daylight, Cloudy, Fluorescent_H, Fluorescent_L, Tungsten, Custom |
|
Still Image
| mode |
Smart Auto, Programme, Scene, Photo Filter, Split Shot, Motion Photo, Beauty Shot, Close up, Magic Frame, Live Panorama, Wigshot(only for SSA), Night Shot |
|
Image Play
Single image, Thumbnails, Advanced Slide Show, Movie Clip, Smart Album
Date Imprinting
Mode: Movie, Smart Movie Movie Size (Frame Rate): 1280 x 720 (30fps, 15fps), 640 x 480 (30fps, 15fps), 320 x 240 (30fps / 15fps), For Sharing (30fps / 15fps) * Format: MP4 (Max. recording time: 20 min.) * Sound Alive On / Off / Mute
Movie Clip
| Recording |
Mode: Movie, Smart Movie Movie Size (Frame Rate: 1280 x 720 (30fps, 15fps), 640 x 480 (30fps, 15fps), 320 x 240 (30fps / 15fps), For Sharing (30fps / 15fps) * Format: MP4 (Max. recording time: 20 min.) * Sound Alive On / Off / Mute |
|
| Effect |
Smart Movie Filter: Miniature / Vignetting / Half Tone Dot / Sketch / Fish-eye / Classic / Retro / Palette Effect 1 / Palette Effect 2 / Palette Effect 3 / Palette Effect 4 |
|
| Edit |
Still Image Capture / Time Trimming |
|
Storage
| Media |
External Memory (Optional): micro SD (up to 2GB guaranteed) micro SDHC (up to 32GB guaranteed), micro SDXC (up to 64GB guaranteed) |
|
| File format |
Still Image: JPEG (DCF), EXIF 2.21, DPOF 1.1, GIF Movie Clip: MP4 (H.264), Audio: AAC |
|
| Image Size |
16M: 4608 x 3456 / 14MP: 4608 x 3072 / 12MW: 4608 x 2592 / 10M: 3648 x 2736 / 5M: 2592 x 1944 / 3M: 1984 x 1488 / 2MW: 1920 x 1080 / 1M: 1024 x 768 |
|
Interface
| Digital Output Connector |
USB 2.0 |
|
| Audio |
Microphone: Mono, Internal Speaker: Mono |
|
| Video Output |
AV: NTSC / PAL (User Selectable) |
|
| DC Power Input |
5V |
|
| Cradle |
No |
|
Power
| Power Source |
type |
Rechargeable Battery: BP-70A / 3.7V , Charger: SAC-48, DC power input Connector: 20 pin , Included Battery may Vary Depending on Sales Region |
Physical Specifications
| Dimension |
Dimension (WxHxD) |
94.4 x 58.0 x 17.7 (20)mm |
| Weight |
|
114g (without battery and memory card media) |
| Operating Temperature |
|
0~40C |
| Operating Humidity |
|
5-85 % |
S/W and PC OS
| Bundle PC S/W |
Built-in PC Software included |
|
| Compatible OS |
Windows XP SP2 / Vista / Windows 7 |
|
System Requirement in General
| For Macintosh |
Power Mac G3 or later Mac OS 10.5 or higher Minimum 256MB RAM 110MB of available hard-disk space USB port CD-ROM drive |
|
| For Windows |
PC with processor better than Intel Core 2 Duo 1.66GHz / AMD Athlon X2 Dual-Core 2.2GHz or higher Minimum 512MB RAM (Over 1GB recommended) Windows XP SP2 / Vista / 7 / 8 250MB of available hard-disk space (Over 1GB recommend) USB 2.0 port CD-ROM drive nVIDIA Geforce 7600GT or later / Ati x 1,600 series or later 1024 x 768 pixels, 16-bit colour display compatible monitor (1280 x 1024, 32-bit colour display recommended) Microsoft DirectX 9.0c or later |
|
Features and specifications are subject to change without prior notification. Images are used for illustrative purposes only.
