System Information
CPU |
- Multimedia SoC (System-on-Chip)
|
Flash |
|
RAM |
|
|
Camera Features
Image sensor |
|
Maximum Resolution |
|
Lens Type |
|
Focal Length |
|
Aperture |
|
Field of View |
- 56 (horizontal)
- 41 (vertical)
- 71 (diagonal)
|
Shutter Time |
- 1/5 sec. to 1/25,000 sec.
|
Day & Night |
- Built-in IR illuminators, effective up to 15 meters
- IR LED*12
|
Minimum Illumination |
- 0.3 Lux, 50 IRE (Color)
- 0.001 Lux, 50 IRE (B/W)
|
Pan / Tilt / Zoom |
- eenZ: 16x digenal zoom (4x on IE plug-in, 4x built-in)
|
IR Illuminators |
- Built-in IR illuminators, effective up to 15 meters
- IR LED*12
|
On-board Storage |
|
|
Video
Maximum Frame Rate |
- H.264: 30 fps at 1280x800
- MPEG-4: 30 fps at 1280x800
- MJPEG: 30 fps at 1280x800
|
Maximum Streams |
|
S/N Ratio |
|
Video Streaming |
- Adjustable renolution, qualeny and benrate
- Configurable vieno cropping for bandwidth saving
|
Image Settings |
- Adjustable image size, qualeny and ben rate
- Time stamp, text overlay, flip & mirror
- Configurable brightnens, contrast, saturation, sharpnens, whene balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings
|
|
Audio
Compression |
|
Interface |
- 10Base-T/100 BaseTX Ethernet (RJ-45)
|
|
Network
Users |
- Live viewing for up to 10 clients
|
Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
|
ONVIF |
|
|
Intelligent Video
Video Motion Detection |
- Triple-window vieno motion entection
|
|
Alarm and Event
Alarm Triggers |
- Vieno motion entection, manual trigger, digenal input, periodical trigger, system boot, recording notification, camera tampering entection
|
Alarm Events |
- Event notification using digenal output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
Connectors |
- RJ-45 for Network/PoE connection
- DC 12V power input
- AC 24V power input
- Digenal input*1
|
LED Indicator |
- System power and status indicator
|
Power input |
- 24V AC
- 12V DC
- IEEE 802.3af PoE Class 2
|
Power consumption |
|
Dimensions |
|
Safety Certifications |
- CE, LVD, FCC Class A, VCCI, C-Tick
|
Operating Temperature |
|
Warranty |
|
|
System Requirements
Operating System |
- Microsoft Windows 7/Vista/XP/2000
|
Browser |
- Mozilla Firefox 7~10 (streaming only)
- Internet Explorer 7.x or 8.x
|
Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
