System Information
CPU |
- Multimedia SoC (System-on-Chip)
|
Flash |
|
RAM |
|
|
Camera Features
Image sensor |
|
Maximum Resolution |
|
Lens Type |
|
Focal Length |
- f = 2.5 mm (FD8151V-F2)
- f = 4 mm (FD8151V-F4)
|
Aperture |
- F2.0 (FD8151V-F2)
- F1.5 (FD8151V-F4)
|
Auto-iris |
|
Field of View |
- FD8151V-F2:
- 110 (horizontal)
- 86 (vertical)
- 142 (diagonal)
- FD8151V-F4:
- 64 (horizontal)
- 53 (vertical)
- 80 (diagonal)
|
Shutter Time |
- 1/5 sec. to 1/32,000 sec.
|
Day & Night |
- Removable IR-cut filter for day & night function
|
Minimum Illumination |
- FD8151V-F2:
- 0.16 Lux, 50 IRE (Color)
- 0.001 Lux, 50 IRE (B/W)
- FD8151V-F4:
- 0.1 Lux, 50 IRE (Color)
- 0.001 Lux, 50 IRE (B/W)
|
Pan / Tilt / Zoom |
- ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
|
On-board Storage |
- MicroSD/SDHC/SDXC card slot
|
|
Video
Compression |
|
Maximum Frame Rate |
- H.264: 30 fps at 1280x1024
- MJPEG: 30 fps at 1280x1024
|
Maximum Streams |
|
S/N Ratio |
|
Dynamic Range |
|
Video Streaming |
- Adjustable resolution, quality and bitrate
- Configurable video cropping for bandwidth saving
|
Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings
|
|
Audio
Audio Capability |
|
Compression |
|
Interface |
|
|
Network
Users |
- Live viewing for up to 10 clients
|
Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
|
ONVIF |
- Supported, specification available at www.onvif.org
|
Interface |
- 10Base-T/100 BaseTX Ethernet (RJ-45)
|
|
Intelligent Video
Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
Alarm Events |
- Event notification using HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
Connectors |
- RJ-45 for Network/PoE connection
- Digital input*1
|
LED Indicator |
- System power and status indicator
|
Power input |
|
Power consumption |
|
Dimensions |
|
Weight |
|
Casing |
- Vandal-proof IK10-rated metal housing
|
Safety Certifications |
- CE, LVD, FCC Class B, VCCI, C-Tick
|
Operating Temperature |
|
Warranty |
|
|
System Requirements
Operating System |
- Microsoft Windows 7/Vista/XP/2000
|
Browser |
- Mozilla Firefox 7~10 (streaming only)
- Internet Explorer 7.x or 8.x
|
Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
