Could your data center benefit from PCIe workload acceleration based on NAND Flash solid-state storage technology? HP PCIe Workload Accelerators for ProLiant ML/DL/SL Server series are PCIe card-based direct-attach solid state storage technology solutions for application performance improvement. They offer excellent latency and enterprise reliability for improving an individual server's throughput, and allow you to implement up to ten times the number of virtual machines compared to typical virtualization environments. With significant energy savings and a reduced footprint, your total cost of ownership will be lower. Performance constrained applications such as on-line transaction processing (OLTP), virtual desktop infrastructure (VDI), or Big Data will greatly benefit by adding a PCIe Workload Accelerator to their server.
Provides Simplicity and Lower Total Cost of Ownership.
HP PCIe Workload Accelerators allows you to implement ten times the number of virtual machines compared to typical virtualization environments. Achieve significant energy cost savings with 70% more compute per Watt of power with server and Accelerators. Reduces data center footprint by hosting an entire database on one HP PCIe Workload Accelerator.
Increase Workload Performance with High Performing HP PCIe Workload Accelerators.
HP PCIe Workload Accelerators enhance server performance, providing four times more transactions per server. Achieve better latency to accelerate applications such as on-line transaction processing (OLTP), virtual desktop infrastructure (VDI), and Big Data. Deliver more IOPS to increase the productivity of your server. Provide you with the most complete portfolio of choices to meet the demands of your data center.
Delivers the High Reliability You Can Count On - In Your Data Center.
HP PCIe Workload Accelerators maintain data accuracy with full data-path error detection. Deliver high availability, typically with power loss protection that protects your data even when the datacenter loses power. Reliably rugged in various environments. HP firmware and drivers deliver compatibility with the HP ProLiant Server series and HP controllers for consistency of performance.
Specifications
| Product dimensions (W x D x H) |
8.78 x 9.58 x 2.5 in |
| Weight ( Imperial ) |
1 lb |
| Weight ( Metric ) |
0.45 kg |
|
Technical Information
| Storage Capacity |
1.60 TB |
| Platform Supported |
PC |
| Features |
Power Loss Data Protection
RAID Support |
|
Drive Performance
|
Maximum Read Transfer Rate
|
2.60 GBps |
| Maximum Write Transfer Rate |
1 GBps |
| Random 4KB Read |
68000IOPS |
| Random 4KB Write |
62000IOPS |
|
Network & Communication
Interfaces/Ports
| Host Interface |
PCI Express 2.0 x8 |
| Network (RJ-45) |
No |
|
Physical Characteristics
| Form Factor |
Plug-in Card |
| Drive Type |
Internal |
| Drive Height |
1/2H |
|
Miscellaneous
| System Requirements |
Operating System(s):
- RHEL 5, 6 (64-bit only)
- VMware ESX 4.x, 5.x
- OEL 5, 6
- Ubuntu 12, 13
- SLES 11 (64-bit only)
- Microsoft Windows Server 2008 R2 SP1 (64-bitsupport only)/ 2012 (64-bit support only)
- Cent OS 5, 6
- Solaris
- Open SUSE 12
|
|
