SilverStone SST-ECW01 Wi-Fi And Bluetooth Combo Mini PCI-E Module

IMG 1 of 1
No Longer Available
Part Number:
388524
(?) Brand:
SilverStone Web Site
Manuf No:
SST-ECW01
SSTECW01
Shipping Weight:
0.3 KG (Includes product packaging)
Estimate Shipping
Date Added:
7/1/2015
Details Files Images & Video
All stock codes associated to this product
SSTECW01, SST-ECW01
ECW01

Wi-Fi 802.11n and Bluetooth combo mini PCI-E module

INTRODUCTION

The SilverStone ECW01 is a mini PCI-E expansion module that integrates Wi-Fi and Bluetooth technology. It has IEEE 802.11n to provide fast wireless Internet experience and Bluetooth 3.0 for connecting to mobile devices and accessories with ease. For users wanting to enable wireless capability on Ultrabook, laptop or desktop with mini PCI-E interface, the ECW01 is an ideal solution.

SPECIAL FEATURES

  • IEEE 802.11b/g/n
  • Independent transmit and receive data path (1T1R)
  • Bluetooth 3.0 + HS
  • Mini PCI-E interface

Specifications

Model No.
 SST-ECW01
IEEE Standard
 802.11 b/g/n
Frequency
 2.412Ghz to 2.484GHz
Interface
 Mini PCI-E
Wireless Data Rates
 Max. 300Mbps (IEEE802.11n)
Encryption
 IEEE 802.11i (WPA, WPA2)
Phase-shift Keying
 DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16QAM, 64QAM
Bluetooth function
 Support Bluetooth 3.0 + HS
Advanced Frequency Hopping (AFH)
WLAN coexistence interface
Fast connection
Dimension
 26.65mm (W) x 24.2mm (L) x 3mm (H)
Extra
 Multiple BSSID feature when used as a wireless bridge
Wake-on-WLAN via Magic packet and wake up frame
Independent transmit and receive data path (1T1R)
weight
 7g
