PERFORMANCE
Pascal-powered graphics cards give you superior performance and power efficiency, built using ultra-fast FinFET and supporting DirectX 12 features to deliver the fastest, smoothest, most power-efficient gaming experiences.
Core/Memory
-
Boost Clock / Base Clock / Memory Frequency
1847 MHz / 1708 MHz / 10108 MHz (OC Mode)
1822 MHz / 1683 MHz / 10010 MHz (Gaming Mode)
1733 MHz / 1607 MHz / 10010 MHz (Silent Mode)
- 8192 MB GDDR5X
Video Output Function
-
DisplayPort x 3
-
HDMI x 1
- Dual-link DVI-D x 1
Features
-
Virtual Reality Ready
-
DirectX 12 Ready
-
Great for 4K
- Gamestream to NVIDIA SHIELD
TORX 2.0 FAN
Just like in games, the exclusive MSI TORX 2.0 Fan technology uses the power of teamwork to allow the TWIN FROZR VI to achieve new levels of cool.
TORX 2.0 Fan design generates 22% more air pressure for supremely silent performance in the heat of battle.
Dispersion Fan Blade
Has a steeper curved blade which accelerates the airflow, increasing its effectiveness.
Traditional Fan Blade
Pushes down a steady airflow to the massive heatsink below.
Double Ball Bearings
Double Ball Bearings give the unique MSI TORX 2.0 Fans a strong and lasting core for years of smooth gaming. They also remain virtually silent while spinning under load, keeping your graphics card cool during intense and lengthy gaming sessions.
Zero Frozr-Stay undetected
First introduced in 2008 by MSI, ZeroFrozr technology has made its mark and is now the industry standard among graphics cards. It eliminates fan noise by stopping the fans in low-load situations. This means you can focus on gaming without the noise of spinning fans.
Catch the Vibe with Cool LED Effects
Each LED can be controlled individually by choosing any of the animation effects availiable in the MSI Gaming App, ranging from responding to your game sounds or music to steady light, breathing and flashing. Of course, you can also turn them off.
HEATSINK
Lurking under the cover of the GAMING graphics card is an engineering masterpiece designed to keep the graphics card cool. Every tiny detail of the intricate heatsink plays an essential part in providing a cool & quiet gaming experience.
Airflow Control Technology
Using advanced aerodynamics, Airflow Control Technology directs more air directly onto the TWIN FROZR VI heat pipes. The special deflectors on the heat sink enlarge the surface area, which means lower temperatures and better gaming.
BACKPLATE
AA powerful graphics card needs a strong build to harness its performance. MSI GAMING X graphics cards are fitted with a solid metal back plate to make it extra tough. The matte black finish completes the TWIN FROZR VI design to perfection.
Specifications
-
Graphics Processing Unit
NVIDIA GeForce® GTX 1080
-
Interface
PCI Express x16 3.0
-
Boost / Base Core Clock
1847 MHz / 1708 MHz (OC Mode)
1822 MHz / 1683 MHz (Gaming Mode)
1733 MHz / 1607 MHz (Silent Mode)
-
Memory Size (MB)
8192
-
Memory Type
GDDR5X
-
Memory Interface
256-bit
-
Memory Clock Speed
10108 MHz (OC Mode)
10010 MHz (Gaming Mode)
10010 MHz (Silent Mode)
-
Output
DisplayPort x 3 (Version 1.4) / HDMI (Version 2.0) / DL-DVI-D
-
Digital Maximum Resolution
7680 x 4320
-
Virtual Reality Ready
Y
-
Maximum Displays
4
-
HDCP Support
2.2
-
DirectX Version Support
12
-
OpenGL Version Support
4.5
-
Multi-GPU Technology
SLI, 2-Way
-
Card Dimension(mm)
279 x 140 x 42 mm
-
Card Weight (g)
1100
-
Power consumption (W)
180
-
Recommended PSU (W)
500
-
Power Connectors
6-pin x 1, 8-pin x 1
