Overview
Clearly Superior
With immaculate tempered glass enclosing the entire chassis, every component
of your build is on display for all to see, including three vivid SP120 RGB LED
fans and a built-in LED controller.
The Final Frontier
Room for up to 6 case fans, and fully compatible with 360mm, 280mm, and 120mm
radiators. Removable fan trays in the front and top of the chassis allows for
additional space or mounting cooling outside of the chassis.
BUILDERS PARADISE
Four-panel tempered glass on every side of the case
Possibly the most beautiful case CORSAIR has ever made. With tempered glass
enclosing the entire chassis, every component of your build is on display for
all to see.
Direct airflow path to keep your CPU and GPU running
cooler
Light up your build with brilliant LED effects. Three included SP120 RGB LED
fans and included LED controller keeps your components running cool.
Room for practically anything
Create as much space as you want with room for up to 6 case fans, virtually
every size radiator or by removing fan trays.
Cable management made simple
Cable routing channels with included velcro cable straps for clean cable
management.
Direct Airflow Path
Drive cages are moved up and out of the path of cool air from the front
intake fans and high-temperature components.
Minimal setup
With tool-free drive installation and three-point dust filter access, the
CORSAIR Crystal 570X is easy to build and even easier to keep clean. Youll spend
less time on setup and maintenance, and more time enjoying your PC.
Contents and Specifications
Package contents |
Crystal Series 570X RGB ATX Mid-Tower Case |
|
Accessory kit |
|
Quick start guide |
|
|
Compatibility |
|
Motherboard |
ATX (Up to 272mm), MicroATX, Mini ITX |
|
|
Technical specifications |
|
Dimensions (L x W x H) |
480 x 234 x 512mm |
Maximum GPU Length |
370 mm |
Maximum CPU Cooler Height |
170mm |
Maximum PSU Length |
225mm |
Expansion Slots |
7 |
3.5 Hard Drive Bays |
2 |
2.5 Drive Bays |
2 |
|
|
Cooling Layout |
|
Front |
3 x 120mm or 2 x 140mm |
|
3 x 120mm RGB LED Included |
Top |
2 x 120/140mm |
Rear |
1 x 120mm |
|
|
Radiator Compatibility |
|
360mm |
Front only |
280mm |
Front only |
240mm |
Front or Top |
120mm |
Front, Top, or Rear |
Dust filters on all intakes
|
|
Front I/O Panel includes |
3-Button RGB Controller, USB 3.0 port (2), Headphone and Microphone
jacks, Power on button |
Specifications
Warranty |
Two years |
|
|
Weight |
10.9kg |
|
|
Case Form Factor |
Mid-Tower |
|
|
Dimensions |
480mm x 234mm x 512mm |
|
|
Case Motherboard Support |
Mini-ITX, MicroATX, ATX (Up to 272mm) |
|
|
Maximum GPU Length |
370mm |
|
|
Maximum CPU Cooler Height |
170mm |
|
|
Maximum PSU Length |
225mm |
|
|
Case Expansion Slots |
7 |
|
|
Case Drive Bays |
(x2) 3.5in |
|
(x2) 2.5in |
|
|
Case Material |
Steel |
|
|
Case Power Supply |
ATX (not included) |
|
|
External Connections |
(x2) USB 3.0 |
|
(x1) Headphone Port |
|
(x1) Microphone Port |
|
|
Fan Mount Locations |
|
Front |
(x3) 120mm or (x2) 140mm |
Top |
(x2) 120/140mm |
Rear |
(x1) 120mm |
|
|
Fans Included |
|
Front |
(x3) 120mm RGB LED |
|
|
Radiator Mount Locations |
|
Front |
120/240/280/360mm |
Top |
240mm |
Rear |
120mm |
|
|
Compatible Corsair Liquid Coolers |
H55, H60, H75, H80i, H90, H100i, H105,
H110 |
