Essentials |
|
Product Collection |
4th Generation Intel Core i7 Processors |
|
Code Name |
Products formerly Haswell |
|
Vertical Segment |
Mobile |
|
Processor Number |
i7-4700HQ |
|
Status |
Launched |
|
Launch Date |
Q2'13 |
|
Lithography |
22 nm |
|
|
|
Performance |
|
# of Cores |
4 |
|
# of Threads |
8 |
|
Processor Base Frequency |
2.40 GHz |
|
Max Turbo Frequency |
3.40 GHz |
|
Cache |
6 MB SmartCache |
|
Bus Speed |
5 GT/s DMI2 |
|
TDP |
47 W |
|
|
|
Supplemental Information |
|
Embedded Options Available |
No |
|
Conflict Free |
Yes |
|
|
|
|
Memory Specifications |
|
Max Memory Size (dependent on memory type) |
32 GB |
|
Memory Types |
DDR3L 1333/1600 |
|
Max # of Memory Channels |
2 |
|
Max Memory Bandwidth |
25.6 GB/s |
|
ECC Memory Supported |
No |
|
|
|
Graphics Specifications |
|
Graphics Base Frequency |
400 MHz |
|
Graphics Max Dynamic Frequency |
1.20 GHz |
|
Graphics Video Max Memory |
2 GB |
|
Graphics Output |
eDP/DP/HDMI/VGA |
|
Max Resolution (HDMI 1.4) |
3840x2160@60Hz |
|
Max Resolution (DP) |
3840x2160@60Hz |
|
Max Resolution (VGA) |
2880x1800@60Hz |
|
DirectX* Support |
11.2/12 |
|
OpenGL* Support |
4.3 |
|
Intel Quick Sync Video |
Yes |
|
Intel InTru 3D Technology |
Yes |
|
Intel Flexible Display Interface (Intel FDI) |
Yes |
|
Intel Clear Video HD Technology |
Yes |
|
# of Displays Supported |
3 |
|
Device ID |
0x416 |
|
|
|
Expansion Options |
|
PCI Express Revision |
3 |
|
PCI Express Configurations |
1x16, 2x8, 1x8 2x4 |
|
Max # of PCI Express Lanes |
16 |
|
|
|
Package Specifications |
|
Sockets Supported |
FCBGA1364 |
|
Max CPU Configuration |
1 |
|
T<sub>JUNCTION</sub> |
100°C |
|
Package Size |
37.5mm x 32mm x 1.6mm |
|
Low Halogen Options Available |
See MDDS |
|
|
|
Advanced Technologies |
|
Intel Turbo Boost Technology |
2.0 |
|
Intel vPro Technology |
No |
|
Intel Hyper-Threading Technology |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O
(VT-d) |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel TSX-NI |
No |
|
Intel 64 |
Yes |
|
Instruction Set |
64-bit |
|
Instruction Set Extensions |
SSE4.1/4.2, AVX 2.0 |
|
Idle States |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
Intel Identity Protection Technology |
Yes |
|
|
|
Security & Reliability |
|
Intel AES New Instructions |
Yes |
|
Secure Key |
Yes |
|
Intel Trusted Execution Technology |
No |
|
Execute Disable Bit |
Yes |
|
Anti-Theft Technology |
Yes |
