| CPU |
| CPU Model |
Realtek RTD1296 |
| CPU Architecture |
64-bit |
| CPU Frequency |
Quad Core 1.4 GHz |
| Hardware Encryption Engine |
|
| Hardware Transcoding Engine |
10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution:
4K (4096 x 2160); maximum frame rate per second (FPS): 30 |
| Memory |
| System Memory |
1 GB DDR4 |
| Storage |
| Drive Bays |
2 |
| Compatible Drive Type* (See all supported drives) |
- 3.5" SATA HDD
- 2.5" SATA HDD (with optional 2.5" Disk Holder)
- 2.5" SATA SSD (with optional 2.5" Disk Holder)
|
| Maximum Internal Raw Capacity |
24 TB (12 TB drive x 2) (Capacity may vary by RAID types) |
| Maximum Single Volume Size |
108 TB |
| Notes |
- "Compatible drive type" indicates the drives that have been tested
to be compatible with Synology products. This term does not indicate the
maximum connection speed of each drive bay.
- The maximum single volume size is not directly related to the
maximum raw capacity.
|
| External Ports |
| RJ-45 1GbE LAN Port |
1 |
| USB 3.0 Port |
2 |
| File System |
| Internal Drives |
EXT4 |
| External Drives |
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
- exFAT*
|
| Notes |
exFAT Access is purchased separately in Package Center. |
| Appearance |
| Size (Height x Width x Depth) |
165 mm x 100 mm x 225.5 mm
|
| Weight |
0.87 kg
|
| Others |
| System Fan |
92 mm x 92 mm x 1 pcs |
| Fan Speed Mode |
- Full-Speed Mode
- Cool Mode
- Quiet Mode
|
| Brightness adjustable front LED indicators |
|
| Power Recovery |
|
| Noise Level* |
19.9 dB(A)
|
| Scheduled Power On/Off |
|
| Wake on LAN/WAN |
|
| Power Supply Unit / Adapter |
60W
|
| AC Input Power Voltage |
100V to 240V AC |
| Power Frequency |
50/60 Hz, Single Phase |
| Power Consumption* |
16.79 W (Access)
5.16 W (HDD Hibernation)
|
| British Thermal Unit |
57.29 BTU/hr (Access)
17.61 BTU/hr (HDD Hibernation)
|
| Environment Temperature |
| Operating Temperature |
5C to 40C (40F to 104F) |
| Storage Temperature |
-20C to 60C (-5F to 140F) |
| Relative Humidity |
5% to 95% RH |
| Certification |
- FCC Class B
- CE Class B
- BSMI Class B
|
| Warranty |
2 Years |
| DSM Specifications |
| Storage Management |
| Maximum Internal Volume Number |
256 |
| Maximum iSCSI Target Number |
10 |
| Maximum iSCSI LUN |
10 |
| Supported RAID Type |
- Synology Hybrid RAID
- Basic
- JBOD
- RAID 0
- RAID 1
|
| RAID Migration |
Basic to RAID 1 |
| Volume Expansion with Larger HDDs |
- Synology Hybrid RAID
- RAID 1
|
| Volume Expansion by Adding a HDD |
Synology Hybrid RAID |
| SSD Support |
| SSD TRIM |
|
| File Sharing Capacity |
| Maximum Local User Accounts |
2048 |
| Maximum Local Groups |
256 |
| Maximum Shared Folder |
256 |
| Maximum Shared Folder Sync Tasks |
4 |
| Maximum Concurrent CIFS/AFP/FTP Connections |
200 |
| Windows Access Control List (ACL) Integration |
|
| NFS Kerberos Authentication |
|
| Log Center |
|
| Syslog Events per Second |
400 |
| Add-on Packages |
| Chat |
|
| Maximum Users |
500 |
| Notes |
- The number of concurrent HTTP connections for Chat was configured to
the maximum.
- CPU and RAM usage were both under 80% when the number of maximum
users was reached.
|
| Cloud Station Server |
|
| Maximum Number of Concurrently Connected Devices |
200 |
| Maximum Number of Synced Files (ext4) |
200,000 / single file reaction time 687 ms |
| Notes |
- The maximum number of concurrently connected devices refers to the
maximum number of devices that can remain connected at the same time.
For more information on file processing capability, please refer to the
reaction time for file processing.
- File reaction time refers to the preparation time required for other
devices to start downloading a 1KByte file from a Synology NAS after the
file has been added to the NAS. RAM expansion was not used during
testing.
- Non-encrypted shared folders were used during the aforementioned
testing.
|
| Download Station |
|
| Maximum Concurrent Download Tasks |
50 |
| exFAT Access (optional) |
|
| Media Server |
|
| DLNA Compliance |
|
| Office |
|
| Maximum Users |
100 |
| Maximum Simultaneous Editing Users |
30 |
| Notes |
- CPU and RAM usage were both under 80% when the number of maximum
users was reached.
- For tested models with expandable memory, the maximum amount of RAM
was installed.
- Client performance may affect maximum simultaneous editing users.
Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
|
| Surveillance Station |
|
| Maximum IP cam (Licenses required) |
15 (including 2 Free License) |
| Total FPS (H.264)* |
450 FPS @ 720p (1280x720)
180 FPS @ 1080p (19201080)
110 FPS @
3M (2048x1536)
80 FPS @ 5M (2591x1944)
40 FPS @ 4K (3840x2160)
|
| Total FPS (H.265)* |
450 FPS @ 720p (1280x720)
450 FPS @ 1080p (19201080)
210 FPS @
3M (2048x1536)
120 FPS @ 5M (2591x1944)
60 FPS @ 4K (3840x2160)
|
| Total FPS (MJPEG)* |
210 FPS @ 720p (1280x720)
70 FPS @ 1080p (19201080)
50 FPS @
3M (2048x1536)
30 FPS @ 5M (2591x1944) |
| Notes |
Surveillance Station throughput is tested with Axis network camera,
using continuous recording with live view from Surveillance Station and
motion detection by camera. Live view and recording are sharing the same
stream from the camera. |
| Video Station |
|
| Video Transcoding |
4K Group 3 (See more) |
| Maximum Transcoding Channel Number |
1 channel, 30 FPS @ 4K (4096 x 2160), H.265 (HEVC), 10-bit or
1
channel, 30 FPS @ 1080p (19201080), H.264 (AVC)/H.265 (HEVC)/MPEG-4 Part 2
(XVID, DIVX5)/MPEG-2/VC-1 |
| VPN Server |
|
| Maximum Connections |
15 |
| Environment & Packaging |
| Environment |
RoHS Compliant |
| Packaging Content |
- Main Unit X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 1
- Quick Installation Guide X 1
|
| Optional Accessories |
- Surveillance Device License Pack
- Disk Holder: Type C
- VS360HD
- VS960HD
|
