MZ-M6E1T0BW | Samsung 1000GB (1TB) mSATA Solid State Drive - V-NAND, 3-Bit MLC, SATA-III - 860 EVO Series

Samsung 1000GB (1TB) mSATA Solid State Drive - V-NAND, 3-Bit MLC, SATA-III - 860 EVO Series

The SSD to trust

The newest edition to the world’s best-selling* SATA SSD series, the Samsung 860 EVO. Specially designed for mainstream PCs and laptops, with the latest V-NAND and a robust algorithm-based controller, this fast and reliable SSD comes in a wide range of compatible form factors and capacities.

Enhanced performance

Speeds are more consistent, even with heavy workloads and multi-tasks. The 860 EVO performs at sequential writes up to 520 MB/s* with Intelligent TurboWrite technology, and sequential reads up to 550 MB/s. The TurboWrite buffer size* is upgraded from 12 GB to 78 GB for faster file transfer.

Boosted endurance

Safely store and render large sized 4K videos and 3D data used by the latest applications, up to 8x higher TBW (Terabytes Written)* than the previous 850 EVO. The latest V-NAND technology gives you up to 2,400 TBW, or is backed by a 5-year limited warranty.*

Smart compatibility

Benefit from faster, more fluid communication with your host system. The refined ECC* algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 EVO more compatible with your computing system.

Multi form factors

Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.

Specifications

General Feature

• Application Client PCs
• Capacity 1,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
• Form Factor 2.5 inch
• Interface SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s &SATA 1.5 Gb/s interface
• Dimension (WxHxD) (29.850.15) x (50.800.15) x Max 3.85 (mm)
• Weight Max. 8.5g
• NAND Type Samsung V-NAND 3bit MLC
• Controller Samsung MJX Controller
• Cache Memory Samsung 1 GB Low Power DDR4 SDRAM

Special Feature

• TRIM Support TRIM Supported
• S.M.A.R.T Support S.M.A.R.T Supported
• GC (Garbage Collection) Auto Garbage Collection Algorithm
• Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
• WWN Support World Wide Name supported
• Device Sleep Mode Support Yes

Performance

• Sequential Read Up to 550 MB/s Sequential Read * Performance may vary based on system hardware &configuration
• Sequential Write Up to 520 MB/s Sequential Write * Performance may vary based on system hardware &configuration
• Random Read (4KB, QD32) Up to 97,000 IOPS Random Read * Performance may vary based on system hardware &configuration
• Random Write (4KB, QD32) Up to 88,000 IOPS Random Write * Performance may vary based on system hardware &configuration
• Random Read (4KB, QD1) Up to 10,000 IOPS Random Read * Performance may vary based on system hardware &configuration
• Random Write (4KB, QD1) Up to 42,000 IOPS Random Write * Performance may vary based on system hardware &configuration

Environment

• Power Consumption *Average: 3.0 W *Maximum: 4.5 W (Burst mode)* Actual power consumption may vary depending on system hardware &configuration
• Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
• Operating Temperature 0 - 70 Operating Temperature
• Shock 1,500 G &0.5 ms (Half sine)

Software

• Management SW Magician Software for SSD management

• Installation Kit Not Available
• Warranty 5 Years Limited Warranty 600 TBW Limited Warranty
