| PRINTER TYPE |
| PRODUCT NAME |
Stylus Photo R2400 |
| PRODUCT CODE |
C11C603031 |
| PRINTING METHOD |
On-demand Inkjet (piezoelectric) |
| NOZZLE CONFIGURATION |
1440 nozzles (180 per colour) |
| MINIMUM DROPLET SIZE |
3pl |
| DURABILITY |
| LIGHTFASTNESS COLOUR# |
75 years on Enhanced Matte Paper |
| LIGHTFASTNESS BLACK & WHITE# |
Over 200 years on Enhanced Matte Paper |
| LIGHTFASTNESS TEST CRITERIA (INDOOR DISPLAY CONDITIONS) |
| Light source |
Fluorescent light |
|
| Intensity |
70k lux |
|
| Temperature |
24oC |
|
| Humidity |
60% RH |
|
| Glass Mount |
2mm, soda lime |
|
| Fade Criteria |
Pure YMC 30% loss at OD=1 |
|
| Display Life Calculation |
Total illuminance/(500 lux x 10 hours x 365 days = 1 year) |
|
Tests developed and conducted by Epson under fluorescent light (indoor display condition) with glass mount. The data is calculated by Epson's accelerated test of prints on specialty media.
For further details on gas and lightfastness, please click here.
# Data is calculated using accelerated simulation of fading under indoor preservation conditions including fluorescent light indoor display. Temperature, humidity and some atmospheric gases may also affect the rate of fading. The estimated lightfastness period does not indicate the colour changing or the durability of the paper itself. Epson recommends that your prints be stored in a photo album (or plastic photo storage box) in acid free, archival sleeves commonly available from most camera shops.
|
| PRINT SPEED |
| BLACK TEXT (MEMO) A4 |
Approx. 6.5 PPM (Draft) *1 |
| COLOUR TEXT (MEMO) A4 |
Approx. 6.5 PPM (Draft) *2 |
| Photo 8" x 10" |
80 sec+ (Photo) *3 |
Print Speed Data Printout Patterns The thumbnail images below show the printout patterns used to determine print speed specifications.
 |
"Second" rating refers to the time taken to print one page. "ppm" rating refers to the number of pages printed in one minute. The computer environment we test under is as follows: CPU: Pentium 4 2.0GHz; RAM: 256MB; OS: Windows XP Professional; Interface/Connectivity: USB 2.0; Software: MS-Word XP/Adobe Photoshop7.0; Paper: Epson Premium Glossy Photo Paper or Plain Paper
*3When printed on Epson Premium Glossy Photo Paper @ 1440x720 dpi |
| RESOLUTION |
| |
5760 x 1440 Optimised dpi using Resolution
Performance Management (RPM) Technology |
| PAPER HANDLING |
| PAPER FEED METHOD |
Friction feed with Paper Feeder |
| PAPER HOLD CAPACITY |
Up to 120 sheets at 90gsm |
| PAPER SIZES |
A3+, A3, A4, A5, A6, Letter, B5, Legal, Executive, Half Letter,
10 x 15cm, 4" x 6", 5" x 8", 8" x 10"
|
| PRINTER SOFTWARE |
| PRINTER DRIVERS |
|
| OPERATING SYSTEMS |
Microsoft Windows 98 / 2000 / Me / XP/ Vista*
Mac OS X 10.2 or 10.5* |
| * Drivers available are downloadable from Tech Epson |
| APPLICATIONS |
|
| (PRINTER SOFTWARE) |
Epson Web-To-Page
Epson Creativity Suite
Epson Easy Photo Print
Epson Darkroom Print
Epson Raw Print (Windows XP & 2000 only) |
| INTERFACES |
| |
USB 2.0 Hi-Speed+ (cable included) |
| |
IEEE 1394* for PC/Mac |
| + To use the USB port, your PC must conform to PC98 specifications, and have Windows 98/ME/2000/XP preinstalled. Consult the documentation provided with your PC for further information about USB connectivity. Note also that printing errors may occur if non-standard cables or more than two hub connections are used. |
| * IEEE 1394 (FireWire) is not supported under Windows Vista operating system. |
| DIMENSIONS |
615mm (W) x 223mm (H) x 314mm (D) |
| WEIGHT |
11.7kg |
| WARRANTY |
| |
12 months return to base |
Standard |
| |
Optional Additional 2 Year Warranty |
3YWR2400 |
| |
Epson Warranty |
| INK CARTRIDGES |
| BLACK INK |
COLOUR INK |
Photo Black (T0591)
Matte Black (T0598)
Light Black (T0597)
Light Light Black (T0599)
|
Cyan (T0592), Magenta (T0593), Yellow (T0594), Light Cyan (T0595), Light Magenta (T0596)
|
PRINT CAPACITY
450 pages at ECMA 5% |
PRINT CAPACITY
519 A4 pages 3.5% |
|
PAPER & INK
The printer ships with full ink cartridges and part of the ink from the first cartridges is used for priming the printer. Yields vary considerably based on images printed, print settings, paper type, frequency of use and temperature.
When an ink cartridge needs replacing, you cannot continue copying or printing even if the other cartridges do not need replacing.
Leave the cartridge that needs replacing installed in the printer until you have obtained a replacement. Otherwise the ink remaining in the print head nozzles may dry out.
To ensure ongoing print quality and trouble free operation, a variable amount of ink remains in cartridge after the Replace Cartridge indicator comes on.
Warning to Epson printer owners. Many well known third party companies claim their inkjet printing papers are compatible with all Epson inkjet printers. Epson has reports from many customers who have used third party's paper and have been very disappointed with the results. When the same customers have changed to genuine Epson paper, they have been amazed and pleased with the colour and quality of their prints. Epson recommends that you do not use any non genuine printing papers if you want to get the best results from your Epson printer. Epson printers are very carefully tuned to ensure Epson inks and Epson's patented MicroPiezo printhead produce the best quality prints using carefully selected Epson paper.
All other brands of printing papers are not wholly compatible with the printer.
Link to for more information and independent studies on media durability by Wilhelm Research
Equipment supplied by Epson Australia is designed to function in conjunction with genuine Epson consumables and accessories specifically configured for it.
The Epson Intellidge Ink System is designed to work perfectly in harmony with the printer and
your choice of media to ensure you get:
- the very best of print quality every print, every time
- and trouble-free, peace-of-mind printing every print, every time
The Epson Intellidge Ink System brings maximum benefits, maximum ink usage and the interchange of Epson cartridges suitable for this model.
The Epson Intellidge Ink System gives you easy-to-see, always available information about all your ink levels.
This printer is designed to be used only with
Genuine Epson Intellidge ink cartridges
Intellidge Ink cartridges are not designed for refill.
 It's now easier for you to identify Genuine Epson cartridges.
Epson is gradually replacing the current hologram with the
new anti-counterfeit Color Shifting Label.
|
| ENVIRONMENTAL CONDITIONS (OPERATING) |
| TEMPERATURE |
10 ~ 35oC |
| HUMIDITY |
20 ~ 80% RH |
| ELECTRICAL SPECIFICATIONS |
| RATED VOLTAGE |
AC 220 ~ 240V |
| RATED FREQUENCY |
50 ~ 60 Hz |
| OPTION |
| Epson Stylus RIP FOR R2400 |
C12C843243 |
