Netgear GS716T 16-Port Gigabit Switch w. 2 x Hot Swap SFP GBIC Slots

Joining NETGEAR`s ProSafe family of Smart 16 Port Switches with simple switch management at no extra cost, this 16 port Gigabit switch is high on value and capability. With 16 10⁄100⁄1000 Mbps ports, each capable of powering 2000 Mbps of data throughput in fullduplex mode, plus two optional fiber ports, it provides fast backbone and connects servers or power users, delivering large amounts of multimedia, image, and video information in no time at all. Ideal for combining 10, 100, and 1000 Mbps devices it delivers 10⁄100⁄1000 automatic speed and full⁄half-duplex sensing plus Auto Uplink™ on every port. Two hot-swappable Small Form- factor Pluggable (SFP)** GBIC slots provide optional fiber connectivity for greater distance. In addition, an intuitive, Web-browser interface offers the simple Smart Switch management, making it a snap to monitor switch performance, configure ports, even set up port trunks, VLANs, and traffic prioritization. Alternatively, use SNMP-based software to manage your Smart Switch.*** Shipped ready for use straight out of the box, it delivers switching that’s easy to set up and use. NETGEAR ProSafe Smart Switches are ideal for adding basic management to your unmanaged networks and extending your managed networks



Specifications





Fixed Ports : 16 x 10⁄100⁄1000 Mbps auto-sensing Gigabit Ethernet switching ports (RJ-45)

Optional Ports : 2 X SFP slots for SFP GBIC Modules

Speed : 10⁄100⁄1000 Mbps

Design : Rack Mount

Management :

IEEE 802.1Q Static VLAN (Up to 64)

Port-based VLAN (Up to 16)

IEEE 802.1p Class of Service (CoS)

Port-based QoS

IEEE802.3ad (manual) Link Aggregation

IEEE 802.1D Spanning Tree Protocol***

RFC 1157 SNMP v1***

RFC 1213 MIB II***

RFC 1643 Ethernet Interface MIB***

RFC 1493 Bridge MIB***

RFC 2131 DHCP client

Jumbo Frame Support (up to 9,600 bytes)***

Private Enterprise MIB***

Port Mirroring Support

Web-based configuration

Configuration Backup⁄Restore

Password Access Control

Firmware upgradeable

Connection Type : RJ-45

Size : 43 mm (H) X 440 mm (W) X 205 mm (D)

Warranty : 5 years
