First PSU in Australia with 5 years return to base warranty
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
12V Combined Output 48A
|
AMD / Intel
Dual Core Support
|
ATX
12V 2.2
|
Complies
EPS 12V
2.91 Version
|
Mirror Finish
|
PCI Express
Connectors
X2
|
S-ATA
Connectors
X6
|
SLI /
Cross-Fire
Ready
|
|
 |
|
|
Complies with ATX 12V 2.2 & EPS 12V version
|
|
|
SLI, Cross-Fire, and Dual Core CPU ready
|
|
|
Next generation four +12V rails(12V1, 12V2, 12V3, 12V4) supports high-end graphic card and PC system (combined loading of 48A)
|
|
|
Independent Voltage Circuit: offers unflappable current delivery under heavy load and makes voltage output more stable
|
|
|
Active Power Factor Correction (PF>0.99) and high efficiency (up to 85%)
|
|
|
Extremely good voltage regulation (3%): provides steady voltage for system
|
|
|
Industrial grade components (capacitor, transformer, etc)
|
|
|
High reliability: MTBF>120,000 hours
|
|
|
Mirror effect housing and reliable 14cm ball-bearing fan
|
|
|
Protections: Over Current, Over Voltage, and Short-Circuit protection
|
|
|
Safety / EMI Approvals: CE, CB, TUV, FCC, UL, CUL, and BSMI certified
|
|
|
8 pins PCI-E connector for next generation graphic card.
|
|
|
|
 |
Total Output Connector: |
|
 |
24-pin Main Connector
X 1 |
 |
8-pin +12V Power Connector
X 1 |
 |
|
 |
4-pin +12V Power Connector
X 1 |
 |
4-pin Peripheral Power Connector
X 7 |
|
|
 |
4-pin Floppy Drive Connector
X 2 |
 |
5-pin S-ATA Connector
X 6 |
|
|
 |
6-pin PCI Express Connector
X 1 |
 |
8-pin PCI-E Connector X 1 |
|
|
 |
8-pin to 6-pin PCI-E Connector X 1 |
|
|
| |
|
Detailed Feature: |
|
 |
 |
|
Quad +12V Rails and EPS Structure
|
|
 |
Mirror Effect Housing |
|
|
 |
Six S-ATA Connectors |
 |
Silent 140mm Fan |
|
|
 |
Noise Preventive Silicon Pad - Effectively reduces vibration noise by as much as 80% |
|
|
| |
|
|
|
|
|
| |
| |
|
Performance: |
|
|
OUTPUT
|
|
Voltage
|
+3.3V
|
+5V
|
+12V1
|
+12V2
|
+12V3
|
+12V4
|
-12V
|
+5VSB
|
|
Max.
Load
|
30A
|
28A
|
18A
|
18A
|
18A
|
18A
|
0.8A
|
3A
|
|
Min
Load
|
0.5A
|
2.0A
|
1.0A
|
1.0A
|
1.0A
|
1.0A
|
0A
|
0A
|
|
Peak
Load
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
3.5A
|
|
Load
Reg.
|
+3,-3%
|
+3,-3%
|
+3,-3%
|
+3,-3%
|
+3,-3%
|
+3,-3%
|
+9,-5%
|
+5,-3%
|
|
Ripple
V(p-p)
|
50 mV
|
50 mV
|
120 mV
|
120 mV
|
120 mV
|
120 mV
|
120 mV
|
50 mV
|

|
| |
|
| |
 |
|
Model
|
W0103RU
|
|
Maximum Power
|
600 Watts
|
|
Color
|
Black
|
|
Switches
|
ATX Logic on-off additional power rocker switch
|
|
PFC (Power Factor Correction)
|
Active PFC
|
|
Cooling System
|
14 cm Fan
SPEED: 1900 RPM (10%)
DIMENSION: 140 X 140 X 25 mm
AIR FLOW: 82 CFM
TEMP. AUTO CONTROL
|
|
Noise
|
16dB at 1300RPM
|
|
P. G. Signal
|
100-500 ms
|
|
Over Voltage Protection Recycle AC to Reset
|
+5V 7.0 Vmax
+3.3V 4.5 Vmax
+12V 15.6 Vmax
|
|
Dimensions
|
16cm(L)x15cm(W)x8.5cm(H)
|
|
Net Weight
|
2.34 kg
|
|
Input Voltage
|
100 VAC~240 VAC
|
|
Input Frequency Range
|
47 ~ 63 Hz
|
|
Input Current
|
115VAC / 8A max.
230VAC / 4A max. |
|
Hold-up Time
|
16ms
|
|
Efficiency
|
up to 85% |
|
|
|
|
|
|
|
