CPU
|
LGA775 socket for Intel Pentium 4/Celeron CPU
Support Inte Pentium Processor Extreme Edition & Intel Pentium D Processor
Support Intel 65nm, Core 2 Duo and Core 2 Extreme
Support Intel next generation Mulit-Core CPU
Compatible with Intel 05B/ 05A and 04B/04A processors
Intel EM64T and Hyper-Threading Technology ready
|
|
Chipset
|
Intel 975X
Intel ICH7R
|
|
Front Side Bus
|
1066/ 800 MHz
|
|
Memory
|
Dual channel memory architecture
4 x 240-pin DIMM sockets support max. 8GB DDR2 800/ 667/ 533 ECC and non-ECC memory
Intel MPT (Intel Memory Pipeline Technology)
ASUS Hyper Path3
|
|
Expansion Slots
|
2 x PCI Express x 16 slot for discrete graphics card
2 x PCI Express x 1
3 x PCI
|
|
CrossFire
|
Support ATI CrossFire graphics cards (both @ x8 mode)
ASUS two-slot thermal design
ASUS PEG Link
|
|
Advanced Thermal Design
|
ASUS 8-Phase Power Design
ASUS Stack Cool2
ASUS Fanless Design: Heat-pipe Thermal solution
|
|
Storage/RAID
|
Intel ICH7R South Bridge:
*1 x UltraDMA 100/66/33
*3 x Serial ATA 3.0Gb/s with Intel Matrix Storage Technology with RAID 0, 1, 5 support
Jmicron JMB363 controller
*1 x UltraDMA 133/100/66
*1 x External Serial ATA 3.0Gb/s (ASUS SATA-on-the-Go) and 1 x Serial ATA 3.0Gb/s with RAID 0, 1, JBOD support
Silicon Image 4723 Hardware RAID controller (ASUS EZ-Backup)
*2 x Serial ATA 3.0Gb/s with RAID 0, 1 support
*Support RAID 10 cross Intel ICH7R and Silicon Image 4723 controller
|
|
LAN
|
Dual Gigabit LAN controllers
*2 x Marvell 88E8053 Gigabit LAN Controller, both featuring AI NET2
Wireless LAN: 54Mbps IEEE 802.11g (ASUS WiFi-AP Solo)
|
|
Audio
|
Realtek ALC882M High Definition Audio 8-channel CODEC
Support Multi-streaming, Jack-sensing and Jack-retasking functions
Anti Pop Function
Coaxial, Optical S/PDIF out on back I/O port
Features Dolby Master Studio technology
- Dolby Prologic IIX
- Dolby Headphone
- Dolby Virtual Speaker
- Dolby Digital Live
|
|
IEEE 1394a
|
TI 1394 controller supports 2 x 1394a ports
|
|
USB
|
Max. 8 USB2.0/1.1 ports
|
|
ASUS Digital Home Accessories
|
1 x Asus DH Remote
1 x ASUS DH Remote Receiver
1 x ASUS MP3-In module
1 x ASUS WiFi-AP Solo Antenna
2 x ASUS EZ-Backup SATA cables
|
|
ASUS AI Lifestyle Features
|
Stack Cool 2 patented fanless cooling system
"SATA on the Go" External SATA connector
AI Quiet
|
|
Overclocking Features
|
AI NOS (Non-delay Overclocking System)
ASUS PEG Link
Precision Tweaker:
- vDIMM: 12-step DRAM voltage control
- vCore: Adjustable CPU voltage at 0.0125 increment
- SFS (Stepless Frequency Selection): allowing FSB tuning from 200MHz up to 400MHz at 1MHz increment
- PCIe x16 Frequency: allowing PCIe x16 frequency from 90MHz up to 150MHz at 1MHz increment"
AI Overclocking (intelligent CPU frequency tuner)
Adjustable FSB/DDR ratio. Fixed PCI/PCIe frequencies.
ASUS AI Booster utility
ASUS C.P.R.(CPU Parameter Recall)
|
|
Other ASUS Special Features
|
CrashFree BIOS 3
EZ-Flash2
Q-Fan2
Multi-language BIOS
MyLogo2
|
|
BIOS
|
8 Mb Flash ROM,AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.3
|
|
Manageability
|
WOL by PME, WOR by PME, Chassis Intrusion, PXE & RPL
|
|
Back Panel I/O Ports
|
1 x Serial Port
1 x Optical + 1 x Coaxial S/PDIF Output
1 x PS/2 Keyboard
1 x PS/2 Mouse
2 x RJ45
4 x USB 2.0/1.1
1 x IEEE1394a
1 x External SATA port
1 x WiFi-AP Solo antenna jack
8-Channel Audio I/O
|
|
Internal I/O Connectors
|
2 x USB 2.0 connectors supports additional 4 USB 2.0 ports
1 x IEEE1394a connector
CPU / 2 x Chassis(system) / 2 x Power Fan connectors
Front panel Audio connector
ASUS EZ-Backup jumpers
Chassis Intrusion connector
CD audio-in connector
MP3-In connector (Red)
SPDIF out connector
System panel connector
Azalia Digital Header
24-pin ATX Power connector
4-pin EATX12V Power connector
|
|
Support CD
|
Drivers
Make RAID driver Disk for Intel ICH7R and JMB 363
ASUS DH Remote Application
ASUS WiFi-AP Solo Wizard
ASUS PC Probe 2
ASUS LiveUpdate Utility
InterVideo Media Launcher (OEM version)
Anti-virus software (OEM version)
|
|
ASUS Digital Home Features
|
ASUS EZ-Backup
- 2 x Serial ATA 3.0Gb/s support hardware RAID 0 or RAID 1 mode
- Plug and play: Default setting in RAID 1 mode, no driver, no BIOS configuration required
ASUS WiFi-AP Solo
54 Mbps IEEE 802.11g and backwards compatible with 11 Mbps IEEE 802.11b
- Software Access point mode
- Station mode : Infrastruceure mode and Ad-Hoc mode
Asus DH Remote
- Power
- Quick Power
- Noise Off
- EZ WiFi
- Full Screen
- AP Launch
- Media Control Zone
ASUS MP3-In
|
|
Accessories
|
1 x ASUS Q-Connector set (USB, 1394, system panel; Retail version only)
InterVideo MEDIA LAUNCHER Suite (OEM version)
1 x Optional Fan
1 x IEEE1394a port module
2 x SATA cables
1 x SATA power cable for 2 devices
1 x UltraDMA 133/100/66 cable
1 x IDE cable
1 x FDD cable
1 x I/O Shield
1 x 2-port USB2.0 module
User's manual
|
|
Form Factor
|
ATX Form Factor, 12"x 9.6"(30.5cm x 24.5cm)
|
