CPU

• Designed for Intel Core Duo, Core 2 Duo socket Mobile 478 processors with 667/533MHz FSB
• Supports Intel Hyper-Threading / XD-bit / EM64T Technology
• Enhanced Intel SpeedStep Technology

Chipset

• Intel 945GT / Intel ICH7MDH Express Chipset

Memory

• 2 X 240-pin DIMM sockets support max. memory capacity 2GB
• Supports Dual channel DDR2 667/533/400 Un-buffered / Non-ECC memory

Graphics

• Integrated Intel Graphics Media Accelerator 950 supports DirectX 9

HDMI 1.2

• Support 1080p and UXGA 1600X1200@60MHz
• Support 7.1 ch HD audio

LAN

• On board Intel 82573L 10/100/1000M controller

Audio

• On board 7.1 channels Intel High Definition Audio CODEC
• Supports auto jack sensing and optical S/P DIF In/Out
• Dolby Master Studio Certificated

Expansion Slots

• 1 x PCI-E X1, 2 x PCI

Internal I/O

• 1 x Floppy port, 1 x UDMA 100/66/33 connector,
• 2 x SATA 1.5Gb/s connectors
• 2 x USB 2.0 headers, 1 x IEEE1394 headers
• 1 x FP-Audio header, 1 x CD-IN

Back Panel I/O

• 1 x VGA, 1 x PS/2 Keyboard, 1 x PS/2 Mouse
• 4 x USB 2.0, 1 x RJ-45 LAN, 1 x IEEE1394
• 1 x Audio connector (Line Out, Line-in, MIC-in, Surround, Rear, Center/Sub)
• 1 x HDMI 1.2

Serial ATA

• Supports 2 ports Serial ATA 1.5Gb/s data transfer rate
• Support RAID 0/1

IEEE1394

• Supports 2 Ports IEEE 1394a at 100/200/400 Mb/s transfer rate

Form Factor

• Micro ATX form factor (245 x 245 mm)
• PCB Color: Orange

RoHS

• 100% lead-free process and RoHS Compliancy

ABIT Engineered

• ABIT CPU Thermal Solution
